Installation (Wiring Diagrams, Fuse Selection & Vehicle Wiring Reference Charts); Type 1 - Directed Directechs DS4+ Installation Manual

Installation (wiring diagrams, fuse selection & vehicle wiring reference charts)

Type 1

with T-Harness (THGMN1)
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram (
(-) Driver Door Trigger
Refer to the Vehicle
wiring reference chart.
Ignition Switch
(black conn. at ignition switch)
Ignition Barrel
Immobilizer
Control Module
(violet conn. under ignition switch)
8
NOT USED
TYPE 2
(black 12-pin connector)
TYPE 1
Siren
Single Wire CAN: Pin 1
OBDll Plug
Black
HS CAN High: Pin 6
Connector
1 8
9 16
HS CAN Low: Pin 14
(-) Parking Lights:
pin 3
1 2 3 4 5 6
A
7 8 9 10 11 12
Clutch Switch
Light Switch
(black 3-pin connector)
Connector
(MUX) Clutch Output: Violet/Brown
No Connection: White/Black
(-) Parking Lights Output: Lt. Green/Black
(-) RAP Off Output: Lt. Blue/Black
Connector
(+) Siren Output: Brown/Red
(-) Hood Input: Gray
HS CAN Low: Tan
HS CAN High: Tan/Black
Single Wire CAN: Lt. Green
Connector
THGMN1
(Optional
T-Harness)
Clutch:
Yellow, pin B
ONLY required for
manual transmission
B C
applications.
8-Pin
White
22-Pin
White
DS4+ DS4
12-Pin
Proper Fuse
Black
Positioning
Slide
to open
It is important to check that the
fuses are positioned correctly.
© 2017-10-19 Directed. All rights reserved.
).
DS4
DS4+
DS4+ GM10
