Chapter 1: Introduction

1.1 Specifications

Model by Resolution
Printing Method
Max Printing Speed
Max Printing Width
Max Printing Length
TM
HEAT Level
Memory
Media
Media Thickness
Ribbon
Media sensor
Fonts
Barcode Types
Interfaces
LCD display
Power Source
Weight
Dimensions
Operating
Environment
Storage Environment
Optional Items
203DPI
Direct Thermal and Thermal Transfer
6 ips (152.4 mm/s)
4.25" (108 mm)
236" (6000 mm)
I
64 MB FLASH ROM, 16 MB SDRAM
Width: 4.56" (116 mm) max, 0.39" (10 mm) min.
OD: 7.3" (186 mm) max.
ID: 3" (76.2mm) min, as standard; 1.5 (38 mm) min., is factory dependent
0.0024" ~ 0.0098" (0.06 ~ 0.25 mm), including liner
Width: 4.56" (116 mm) max.
Length: 1968' (600 m) max.
OD: 3.3" (84 mm) max.
ID: 1" (25.4 mm) min.
Ink side: both In and Out
Upper&Lower Reflective (Adjustable) / Transmissive (Adjustable)
Five built-in dot matrix ASCII fonts, user-downloadable TrueType Fonts
1D Barcode: Code 39, Code 93, Code 128/subset A,B,C, Codabar,
Interleave 2 of 5, UPC A/E 2 and 5 add-on, EAN-13/8/128, UCC-128, etc.
2D Barcode: MaxiCode, PDF417, Data Matrix, QR Code, etc.
RS-232 Serial, 10/100 M Adaptive Ethernet, USB DEVICE 2.0, USB
HOST, Centronics Parallel
Graphic Dot Matrix
100 ~ 240 V, 50/60 Hz, 3.5 A
33.06 lbs (15 kgs)
W 11.3" (286 mm) x D 17.6" (448 mm) x H 10.7" (271 mm)
Temperature: 32 F ~ +104 F (0 C ~ 40 C)
Relative humidity: 5% - 85% non condensing
Temperature: -40 F ~ +140 F (-40 C ~ 60 C)
Relative humidity: 5% - 85% non condensing
Rotary Cutter, External Label Rewinder
Chapter 1: Introduction
300DPI
6 ips (152.4 mm/s)
4.17" (106 mm)
157" (4000 mm)
I
4
