Postek I Series User Manual page 31

I Series User's Manual
initiate the print job.
7. Removed the peeled label, and the printer will resume printing.
8. If the peeling position of the label needs to be adjusted, press the [MENU] button to enter the
settings menu. Select "PEEL OFFSET" and adjust the value accordingly.
Cutter Mode (Cutter accessory required)
The steps to set the printer to Cutter Mode are as follows:
1. Connect the printer to PC using the preferred communication port and connect the printer power
supply.
2. Install the media and ribbon as shown above, turn on the printer and wait for the printer to boot
normally.
3. After "READY" is displayed on the screen, press the [MENU] button to enter the setting menu.
Find "CUT MODE" in the menu and select it, select "ON" to enable Cutter Mode.
Peeler Mode and Cutter Mode can't be both enabled at the same time, please turn off Peeler
Mode first before switching Cutter Mode on.
4. Gently press the [MENU] button twice to exit the setting menu.
5. Reset the cutter before use. To reset, press and hold the [CANCEL] button until three indicators
start blinking (This process takes around 4 seconds), release the button and press it again to finish
the reset.
Please reset the cutter before installing the media to prevent any issues with installation.
6. Turn the power supply off. Load the ribbon and media in the order as shown above. Thread the
media through the opening on the cutter as shown in Figure 3-2 (only Media Core Supporting
Blade mechanism is illustrated).
7. Turn on the printer and press the [MEDIA CALIBRATION] button, the printer will automatically
feed labels and the media calibration is done.
Figure 3-2 Cutter Mode
Chapter 3: Operations and Settings
27
