Connecting To A Water Source; Connecting The High-Pressure Washer To The Mains Water Supply - Stihl RE 100 PLUS CONTROL Instruction Manual

English
6.5.2 Removing the nozzle
2
► Press nozzle (1) and spray lance (2) together and turn
until stop.
► Pull nozzle (1) and spray lance (2) apart.

7 Connecting to a water source

7.1 Connecting the high-pressure washer to the
mains water supply
Connecting the water filter
If the high-pressure washer is operated with sandy water or
water from cisterns, a water filter must be connected to the
high-pressure washer. The water filter filters sand and dirt
out of the water and thus protects the components of the
high-pressure washer from damage.
Depending on the market, the water filter may be included
with the high-pressure washer.
► Unscrew the connector.
18
1
1
► Screw the water filter (1) onto the water supply and tighten
by hand.
Connecting the water hose
The water hose must meet the following requirements:
– The water hose has a diameter of 1/2".
– The water hose is between 10 m and 25 m long.
► Connect the water hose to a tap.
► Turn on the water tap fully and flush the water hose with
water.
Sand and dirt will be flushed out of the water hose. The
water hose will be vented.
► Turn off tap.
2
1
► Push the coupling (1) onto the connector (2).
The coupling (1) engages with an audible click.
► Turn tap fully on.
7 Connecting to a water source
0458-004-0121-A
