English
► Insert water intake screen (2) into the coupling of the
water hose (3).
Connecting the water hose
3
2
1
► Fill the water hose (1) with water so that no air is present
in the water hose any more.
► Screw the coupling (2) onto the connector of the pressure
washer (3) and tighten by hand.
► Attach the suction cup (4) to the water source so that the
suction cup (4) does not touch the ground.
► If the spray gun is fitted to the high-pressure hose:
Remove the spray gun.
► Hold the high-pressure hose downwards.
► Switch on the high-pressure washer until an even water jet
flows out of the high-pressure hose.
NOTICE
If the high-pressure washer does not suck in water, the
pump may run dry and the high-pressure washer may be
damaged.
► If no water escapes from the high-pressure hose after two
minutes: Switch off the high-pressure washer and check
the water supply.
► Switch off the high-pressure washer.
► Connect the spray gun to the high-pressure hose.
► Press and hold down the spray gun trigger.

► Switch on high-pressure washer.

20
8 Connecting the pressure washer to the
8.1
1
4
► Set the toggle switch to the 0 position.
► Remove the connecting cord (2) from the holders (3).
► Plug the plug of the connecting cord into a correctly
installed socket.
9 Switching the pressure washer on and
9.1
When the pressure washer is switched on, voltage
fluctuations may occur under unfavorable mains conditions.
The voltage fluctuations may negatively affect other
connected electrical appliances.
8 Connecting the pressure washer to the power supply

power supply

Connecting the pressure washer to an electric

power supply
3
2
3
off
Switch on high-pressure washer
1
0458-004-0121-A
