3. Hold the both sides of the assembly
4. Insert the new Feed Roller Assembly into
5. Put the roller cover back until you hear a
NOTE:
•
•
42 FileScan 3125c User's Manual
to pull it out carefully from its
compartment.
its compartment;
a) mount the shaft with a white cap
at the end of the shaft into the
mounting socket (in white) at the left
side of compartment.
b) Then, insert and push the whole
assembly back into its compartment
until it snaps into place.
"click".
The recommended replacement point for your Feed Roller Assembly is after
scanning approximately 30,000 scans through the feeder.
Please contact your local resellers for purchasing new Feed Roller Assembly.
a
b
