- Page 1 OPERATION MANUAL PVC Flooring Cutter LT-200 www.dcutproducts.com CUTTING AND C...
- Page 2 7. Make sure tool is secure. Operate only on a firm substrate or solid stand. 8. Use the right tool. Do not force the D-Cut Multi-flooring Cutter or use it for a job for which it was not designed; use only on approved materials.
- Page 3 Installation of the Cutter Insert the handle base into the handle as shown. Warning: Do not put your fingers against the sharp edge of the blade at any time. Insert material between the cutting blade and the base, flush with the gauge as shown and hold the material then push handle down to complete a cut.
- Page 4 P a r t L i s t...
- Page 5 Parts Q’ty Parts Q’ty Hex Head Screw M4 × 25 Working Table Washer Ball Handle Φ Rubber Feet A Hook B Lock Nut M4 Handle Nylon Block Stopper Cutter Base Rotating Shaft Spring Pin Hex Head Screw M5 × 8 Spring Hex Headless Screw M5 ×...
