Summary of Contents for D-CUT LT-330
- Page 1 OPERATION MANUAL PVC Flooring Cutter LT-330 www.dcutproducts.com CUTTING AND C...
- Page 2 7. Make sure tool is secure. Operate only on a firm substrate or solid stand. 8. Use the right tool. Do not force the D-Cut Multi-flooring Cutter or use it for a job for which it was not designed; use only on approved materials.
- Page 3 Installation of the Cutter Insert the handle into the handle base as shown. Warning: Do not put your fingers against the sharp edge of the blade at any time. Changing the Blade Use the provided Allan wrench to remove the five screws, then hold the blade by each end and carefully move the blade out of blade holder.
- Page 4 Straight Cut Insert the material between the cutting blade and the base, flush with the gauge as shown and hold the material then push handle down to complete a cut. 45° Cut Swing the angle attachment to 45°. Insert material between the cutting blade and the base, against the angle attachment as shown, then push the handle down to complete a cut.
- Page 5 P a r t L i s t...
- Page 6 Parts Q’ty Parts Q’ty Hex Head Screw M4 × 25 Handle Ball φ Plain Washer Handle Rubber Feet A Hook B Nylon Lock Nut M4 Rotating Shaft A Customized Ring φ10 Hex Head Screw M5 × 16 Pressure Plate Customized Screw M8 × 22 Customized Ring φ8 Nylon Bar Hex Head Screw M6 ×...
