- Page 1 OPERATION MANUAL Flooring Cutter DP-340 www.dcutproducts.com...
- Page 2 SAFETY RULES FOR THE FLOORING CUTTER READ AND UNDERSTAND THIS INSTRUCTION MANUAL BEFORE OPERATING THEMULTI-FLOORING CUTTERS. 1. If you are not thoroughly familiar with the operation of Multi-flooring Cutter, obtain advice from a qualified instructor or call 630-916-9100 USA 2. Stay alert. Do not operate while under the influence of drugs, alcohol, or medication.
- Page 3 CUTTING AND C Assembly Assemble the table and handle to the cutter base with provided screws and bolts as shown. Warning: Do not put your fingers against the sharp edge of the blade at any time. Straight Cut Insert material between the cutting blade and the base, flush it with the guide bar as shown and hold the material...
- Page 4 Changing the Blade Use the provided Allan wrench to remove the five screws, then hold the blade by each end and carefully move the blade out of blade holder. Note: the flat side of the blade should face the table. Warning: Do not put your fingers against the sharp edge of the blade at any time.
- Page 5 PARTS LIST...
- Page 6 PARTS LIST Parts Q’ty Parts Q’ty Nylon Bar Holder Φ Screw M4×10 Nylon Bar Blade Main Base Hook Bolt M8×40 Screw M840 End Cap Spring Washer Φ5 × Screw M5×10 × Stopper × Blade Holder Blade Holder Base Screw M5×12 Shaft Nylon Wheel Washer 6...
