- Page 1 OPERATION MANUAL D-Cut Laminate Cutter LU-215 www.dcutproducts.com CUTTING AND C...
- Page 2 Assembly Use provided Allan wrench, screws, bolt and nuts to assemble the blade onto the base and handle as shown. Warning: Avoid contact with the steel teeth along the cutting slot, which may cause injury. Cross Cut Place the flooring plank onto the cutter base and position the stopper in the appropriate slot at the required length.
- Page 3 Lengthwise Cutting When cutting laminate lengthwise, remove the stopper from the cutter base. Mark a line on the laminate plank and place it on the base. Hold it down firmly while pushing down the cutter blade. Small teeth located along the cutting slot will keep the laminate plank from slipping.
- Page 4 P a r t L i s t Parts Q’ty Parts Q’ty End Cap Working Table Screw M6×15 Stopper Assemble Spring Washer Φ6 Left Steel teeth Flange Nut M8 Locker Nut Blade Blade Base Knurled Thumb Screw Customized Screw M10 Handle Washer Right ABS Handle...
