1 and 2: Morpho connectors
3, 4, 5, and 6: Arduino connectors
7: 5 V only current capability table
8: STL40DN3LLH5
9: Current sense 7 mΩ shunt resistor
10: ST715PU33R
1.2.1 USB Type-C™ connector
The USB Type-C™ receptacle (CN1) gathers the V
USB 2.0 data lines (DP, DM), before dispatching data to the major functional blocks.
UM2973 - Rev 1
Figure 5. X-NUCLEO-SRC1M1 main functional blocks (bottom view)
automotive-grade dual N-channel 30 V, 0.016 mΩ, 11 A STripFET H5 power MOSFET
high input voltage LDO linear voltage regulator
2
5
9
6
7
10
8
path and the main connections, such as CC lines and
BUS
UM2973
Hardware architecture
1
3
4
