Figure 4. X-Nucleo-Src1M1 Main Functional Blocks (Top View) - ST X-NUCLEO-SRC1M1 User Manual

• if the STM32 does not embed a UCPD peripheral, connect JP2 and JP3 jumpers to CC1_noUCPD and
CC2_noUCPD, respectively.
When plugged onto an
ways:
• through the
• through the CN3 screw connector and thanks to the integrated
supplies the entire system.
1 and 2: Morpho connectors
3, 4, 5, and 6: Arduino connectors
7: USB Type-C™ connector (CN1)
8: Provider path screw connector (CN3) + LED
9: Jumpers for CC lines configuration (JP2 and JP3)
10: 3.3 V LED
11: Jumpers for the board self-power (LDO out + NRST)
12: TCPP02-M18
13: ECMF02-2AMX6
14: ESDA25P35-1U1M
UM2973 - Rev 1
STM32 Nucleo development board, the expansion board can be supplied in two different
STM32 Nucleo ST-LINK supply by using the development board internal LDO;
Figure 4. X-NUCLEO-SRC1M1 main functional blocks (top view)
USB Type-C™ source protection
common mode filter + ESD protection
TVS diode
1
11
3
4
8
10
ST715PU33R
9
12
13
14
7
UM2973
Hardware architecture
LDO linear regulator (U2) that
2
5
6
page 4/25
