Telos Zephyr User Manual page 233

ZEPHYR COMPATIBILITY
CCS
CDQ2000
N/S
LAYER 3
LAYER 2
J- STEREO YES
DUAL YES
MONO YES
128 MONO YES
N/S
G.722
GENERAL NOTES:
•YES = Compatible. Zephyr Layer II operation requires Layer III+II firmware and hardware.
•N/S=Not supported by other codec.
•Zephyr supports ISO/MPEG Layer II at 48kHz sampling only.
•Zephyr supports "CCS CDQ protocol compatible" channel splitting for ISO/MPEG Layer II stereo and
mono 128 modes.
•Zephyr models 9200,9201, or 9202 required for stereo and mono- 128 modes
CCS NOTES:
•CDQ 1000: Switch off H.221 (DIP switch 7 , on back, in down position; to "AUTO" mode) on CDQ to
transmit from CDQ to Zephyr. Terminal adapter must have "BONDING" turned off and be set to
64/56Kbps.
•CDQ 2000: Switch to "Decoder independent from encoder" (Decoder DIP switch #6 in up position;
"INDEPENDENT"). Terminal adapter must have "BONDING" turned off and be set to 64/56Kbps.
•Prima: must be set to front panel option "DECODER/GENERAL/INDEP=YES" OR Serial port command
"DIN YES". * Newer Primas also support layer 3 and are reportedly compatible.
COMREX NOTES:
•DX200 must have ERROR PROTECTION set to "ON" and IMUX set to "TELOS/CCS" or "CCS".
Terminal adapter must have "BONDING" turned off and be set to 64/56Kbps.
•Nexus must have "H.221" off.
1- 97
CCS CCS
CDQ1000 CDQPrima Micro 56
N/S *
N/S YES
N/S YES
YES YES
N/S YES
YES YES
PAGE 1 of 2
CCS COMREX
DX200
Micro 64
N/S N/S
N/S YES
N/S YES
N/S YES
N/S YES
YES YES
Section 15 APPENDICES
COMREX INTRAPLEX
DXP/DXR 4400
NEXUS
N/S N/S
N/S N O
N/S N/S
N/S N/S
N/S N/S
YES N/S
