Safety precautions
FP Series: Warnings/Cautions
Be sure to read this section before use.
Refer to "Electric Actuator Motorless (CB-055A)" and "Electric Actuator EBS-M/EBR-M Series
(CC-1422A)" for general and product-specific precautions.
Product-specific cautions: Electric actuator EBS-M/EBR-M/EBS-L/EBR-L/EKS-L/ETS/ETV/ECS/ECV Series
1. Common
CAUTION
Do not hit the trolley table against the stroke end.
Indicate the maintenance conditions in the device's
instruction manual.
The product's functionality may drop too low to maintain an
appropriate safety level depending on usage conditions,
working environment and maintenance status. With correct
maintenance, the product functions can be used to the fullest.
Regarding installing, setting up, and/or adjusting
the actuator, read through the instruction manual
and operate correctly.
The product is manufactured in conformity with the related
standards. Do not disassemble or modify the product.
Refer to the instruction manual of the motor mounted to the
product and control for your safety before wiring and designing.
The customer is responsible for confirming the
compatibility of CKD products with the customer's
systems, machines and equipment.
1. Common
CAUTION
This product uses food-grade (NSF H1) lubricants.
Do not mix with other greases.
Regularly inspect the product at least two or three
times a year to check that it operates correctly.
Grease the product once every 3 months or at
100km intervals as a general guide. Note that
grease interval differs depending on the working
conditions. It is recommended to determine the
interval based on initial inspection. Refer to the
instruction manual for details.
If the product has been out of use for one month or more,
perform a test run before starting the actual operation.
Products and related technologies in this catalog
The products and related technologies in this catalog are subject to US Export Administration Regulations (EAR),
and display of EAR-compliant products is marked on the product page. For export or provision of products or
related technologies subject to EAR regulations, we request that the US Export Administration Regulations (EAR)
be observed appropriately.
Design/selection
2. EBS-M/EBR-M Series
DANGER
Use a DC stabilized power supply (48 VDC±10% or
24 VDC±10%) for the motor, control, and input/
output circuit power supplies. Connecting directly to
the AC power supply may cause fire, explosion,
damage, etc.
CAUTION
Select a power supply which provides ample capacity
b a s e d o n t h e n u m b e r o f i n s t a l l e d p r o d u c t s .
Malfunction may occur if there is no excess capacity.
(Guideline:
56...8.6A/base)

Use/maintenance

2. EBS-M/EBR-M Series
CAUTION
The circuit board inside the product has capacitors
connected between the circuits and the metal body to
prevent damage due to static electricity. Avoid
withstand voltage and insulation resistance tests on
equipment with this product installed. If tests are done,
the product will be damaged. If necessary for the
equipment, remove the product before doing the test.
If the actuator and controller combination is
changed, be sure to confirm the programs and
parameters prior to operation.
Otherwise, there is a risk of unexpected accidents.
Precautions for export
35...4.0A/stand, 42...5.2A/stand,
