CKD FP Series Manual page 5

Anti-bacterial/bacteria-removing filter
WARNING
Perform a periodic inspection once every six months
or less to check for any cracks, scratches, and other
damage to the plastic bowl and transparent housing.
If cracks, scratches or other deterioration are found,
they may cause damage. Please replace the bowl or
the product with a new one.
Check the plastic bowl periodically for contamination.
If parts are heavily contaminated or if transparency has
decreased, replace with a new bowl.
Use a diluted neutral household detergent to wash parts,
and then rinse well with clean water. Use of other agents
could result in breakage.
Removing the bowl
Stop the working fluid supply. Release the pressure
in the bowls completely and make sure that there is
no residual pressure before removing the bowls.
Remove air filter drain.
Components could malfunction if moisture flows
into the secondary side.
Do not disinfect or clean using alcohol. It may
deteriorate or damage the plastic part.
CAUTION
Anti-bacterial and bacteria removing effects lessen
when there are dirt or oil deposits in the filter element.
P e r i o d i c a l l y i m p l e m e n t i n s p e c t i o n s a n d
replacements. Contact CKD for maintenance details.
Do not modify the product.
WARNING
The chemical resistance of plastic parts is shown below.
Avoid using products in an atmosphere where chemicals are contained in working fluid or atmosphere, or where they could adhere to parts.
Use in the above state could lead to bowl damage and accidents.
Chemical resistance of plastic bowl and clear housing
Types of chemicalsCategories of chemicals
Sodium hypochlorite, hydrochloric acid, sulfuric acid,
Acids
hydrofluoric acid, phosphoric acid, chromic acid, etc.
Inorganic
Alkali substances such as caustic soda, caustic potash,
chemicals Alkalines
calcium hydroxide, aqueous ammonia, and sodium carbonate
Inorganic salts Sodium sulfide, sodium nitrate, potassium bichromate, sulfate of soda, etc.
Aromatic
Benzene, toluene, xylene, ethyl benzene, styrene, etc.
Hydrocarbons
Chlorinated Methyl chloride, ethylene chloride, methylene chloride,
aliphatic acetylene chloride, chloroform, trichlene, perchlene,
hydrocarbons carbon tetrachloride
Chlorinated aromatic Chlorobenzene, dichlorobenzene, benzene hexachloride (B/H/
hydrocarbons C), etc.
Petroleum components Solvent naphtha, gasoline, kerosene
Alcohols Methyl alcohol, ethyl alcohol, cyclohexanol, benzyl alcohol
Phenol Carbolic acid, cresol, naphthol, etc.
Organic
Ethers Methyl ether, methyl ethyl ether, ethyl ether
chemicals
Ketones Acetone, methyl ethyl ketone, cyclohexanone, acetofeNN, etc.
Carboxylic Formic acid, acetic acid, butyl acid, acrylic acid, oxalic acid,
acids phthalic acid, etc.
Dimethyl phthalate (DMP), diethyl phthalate (DEP), dibutyl
Esters
phthalate (DBP), dioctyl phthalate (DOP)
Oxyacids Glycol acid, lactic acid, malic acid, citric acid, tartaric acid
Nitro
Nitromethane, nitroethane, nitroethylene, nitrobenzene, etc.
Compounds
Amines Methylamine, dimethylamine, ethylamine, aniline, acetanilide, etc. Additive of brake oil
Nitriles Acetonitrile, acrylonitrile, benzonitrile, acetoisonitrile, etc.
393
Use/maintenance
Chemical resistance of plastic
Consult CKD when using in environments filled with the following chemicals.
Check whether the testing solutions, sealants and adhesives contain the following chemicals.
Main products of chemicals
Read instructions and precautions attached with the
product before use or maintenance. Wash your hands
before attaching new elements.
Drainage method
Drainage starts when the cock is turned in
the O direction, and the discharge stops
when the cock is turned in the S direction.
Tighten by hand in the S direction.
Plastic bowl
Removing the resin bowl
Latch
(Press down
and turn.)
Bowl guard
This filter cannot be flushed with air, water, etc., and reused.
When 1 year (6,000 hours) has passed or the pressure
drops to 0.1MPa, replace the element with a new one.
We ask that customers perform element replacement maintenance by themselves.
During element replacement, take consideration that
bacteria, foreign materials, or foreign matter deposits in
the primary side do not flow into the secondary side.
While operating, do to apply vibration, impact, or other external force from tube.
General applications
Sterilization, acid washing of metals, acidic degreasing
solutions, coating treatment solutions, etc.
Alkaline degreasing solution for metals
Soluble cutting oil, leakage detection agent
Contained in paint thinner (benzene, toluene, and xylene)
Organic solvent-based washing solution for metals (trichlene,
perchlene, carbon tetrachloride, etc.)
Agricultural chemicals
Used as antifreezing agent
Leakage detection agent
Disinfectant solution
Additive of brake oil
Dyes/oxalic acid for aluminum processing, phthalic acid for
paint base and leakage detection agents
Lubricant, synthetic oil, rust preventing agent additive plasticizer
for synthetic resin
Raw material for nitrile rubber
Nylon
x
x
x
x
x
x
x
x
