Intense TRACER 279 EXPERT Manual page 10

F
S T E P 4 C O N T I N U E D . . .
Once everything is lined up and in position, reinsert
the axle and tighten using the integrated lever on the
non-drive side (left), turning clockwise until tight (F).
Reinstall the lever within the axle by pushing it firmly
back in place. Then with a 5mm Allen key on the
drive-side of the bike tighten (G) the axle to 11Nm, in
a counterclockwise direction.
You can now take the lock off the rear derailleur (H). To
do this, gently push the derailleur cage forward a little
and the cage lock will automatically release. Slowly let
the derailleur arm move backward into position.
G H
18 19
