TORQUE
SPECIFICATIONS
Achieving correct torque is vital to ensuring the
proper performance and function of the Tracer
frame. Failure to do so could result in suboptimal
performance of your frame as well as premature wear
and tear of individual parts. In addition to this chart,
torque values are laser etched onto corresponding
hardware for your reference.
Rear Axle (Non-Drive Side): Quick Lever, 11Nm / 100in-lbs
Derailleur Hanger: 25Nm / 221in-lbs
Hanger Hardware: 2Nm / 18in-lbs
64
5mm HEX, 5Nm / 45in-lbs
5mm HEX, 16Nm / 140in-lbs
5mm HEX, 16Nm / 140in-lbs
5mm HEX, 16Nm / 140in-lbs
5mm HEX, 16Nm / 140in-lbs
8mm HEX, 7Nm / 61.96in-lbs
5mm HEX, 14Nm / 125in-lbs
65
