Mounting Height, Clearance, & Ducting
Titan Use, Care, and Installation Guide
C
n .
m i
D
x .
m a
Hood Heights
minimum ducted (A)
maximum (B)
Ceiling Heights
minimum ducted (C)
maximum (D) 112-1/2" (9' 4-1/2") 150" (12' 6")
Installation Instructions
n .
m i
x .
m a
i n .
.
" m
a x
2 4
" m
3 4
"
3 6
Standard Extension
Duct Cover Duct
30" 49"
42-1/2" 80"
90" (7' 6") 109" (9' 1")
A
B
Cover
9
