Mounting Height, Clearance, & Ducting
Venezia Use, Care, and Installation Guide
D
n .
m i
E
n .
m i
F
x .
m a
Hood Heights
minimum ducted (A)
minimum recirculating (B)
maximum (C)
Ceiling Heights
minimum ducted (D)
minimum recirculating (E)
maximum (F)
Installation Instructions
n .
m i
n .
m i
x .
m a
i n .
.
" m
a x
2 4
" m
3 4
"
3 6
Standard Extension
Duct Cover Duct
27" 45"
31-1/2" 49-1/2"
44" 80"
87" (7' 3") 105" (8' 9")
91-1/2" (7' 7-1/2") 109-1/2" (9' 1-1/2")
114" (9' 6" ) 150" (12' 6")
A
B
C
Cover
