Mounting Height, Clearance, & Ducting
Titan Island Use, Care, and Installation Guide
C
n .
m i
D
x .
m a
Hood Heights
minimum ducted (A)
maximum (B)
Ceiling Heights
minimum ducted (C)
maximum (D)
Installation Instructions
m i
m a
i n .
.
" m
a x
2 4
" m
3 6
"
3 6
Standard Extension
Duct Cover Duct Cover
32-1/2" 49"
50" 78"
92-1/2" (7' 8-1/2") 109" (9' 1")
122" (10' 2") 148" (12' 4")
A
n .
B
x .
9
