OM POWER OM2000+ Manual page 19

This is not the actual physical setting of the primary voltage tap. It is just information for the
processor, which protects the permitted limits (up or down) for a given value of the primary
voltage.
Three different bar graphs can be defined using BARG1, BARG2 or BARG3 buttons.
Press BARG1 button.
Type in the actual setting of the primary
voltage tap and press ENT.
Type of supported TCVR and working
Press EXIT twice to go back to the Menu
frequency are visible on the display.
display.
Press MEAS button.
Type of supported TCVR and working
frequency are visible on the display.
Pressing MEAS displays
Type of supported TCVR and working
instantaneous values of the basic amplifier
parameters are displayed.
frequency are visible on the display.
NOTE: You can FREEZE the screen and/or allow
constant monitoring.
AUTO LED is ON.
AUTO LED is ON.
this screen.
AUTO LED is ON.
19
