Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Connect the 10-pin, 12-pin and 14-pin harnesses to DB3, then wait until the LED turns
1
ON solid red.
Important! Do NOT depress the brake pedal.
2
Press the Push-to-Start (PTS) button once to turn the ignition ON. The LED starts flashing
orange.
3
The LED turns ON solid green for 3 seconds,then shuts OFF.
4
Press the PTS button once more to turn the ignition OFF.
You have successfully completed the module programming sequence.
16
403.VW08 1.35 2020 Audi Q7 (Smart Key)
