Directed DIRECTECHS DB3 Installation Manual page 12

Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
12 403.VW08 1.35 2020 Audi Q7 (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Description
No Connection
(-) PTS Output
No Connection
(-) Trunk Output
No Connection
(+) Brake Output [2]
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Description
No Connection
No Connection
No Connection
No Connection
No Connection
(-) Hood Switch Input
No Connection
No Connection
No Connection
No Connection
Connects To
Wire Location
No Connection
Rear of Center Console, black 17 pin plug, pin 1
Rear of Center Console, black 17 pin plug, pin 2
Rear of Center Console, black 17 pin plug, pin 3
Must use three 1A diodes.
Comfort System Module in left rear quarter panel, below fuse box,
blue-white 32 pin plug, pin 25
Comfort System Module in left rear quarter panel, below fuse box,
blue-white 32 pin plug, pin 26
Comfort System Module in left rear quarter panel, below fuse box,
blue-white 32 pin plug, pin 10
No Connection
No Connection
No Connection
Driver Firewall, harness to engine compartment
Important! There are two possible connections, make sure to follow
the installation diagram.
Comfort System Module in left rear quarter panel, below fuse box,
black-white 32 pin plug, pin 12
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color
- Yellow/Gray (PTS 1
- alternate)
- White/Gray (PTS 2
- alternate)
- Blue/Yellow (PTS 3
- alternate)
Yellow/Gray
White/Gray
Blue/Yellow
+ Black/Red (alternate
+ location)
Black/Red
(+/-) Wire Color
