STEP #3
INSTALLATION OF UPPER SIDE RAIL INTO
THE HEADBOARD & FOOTBOARD
STEP #3.1
On both ends of the Upper side rail are holes
for the bolt to pass through that correspond to
the holes on the posts for headboard and
footboard with pre-installed nuts. Align and
insert the Allen bolts (AA) in each hole and
tighten with Allen wrench provided, as in
DETAIL F.
After assembly, re-tighten all bolts to a snug
fit. DO NOT OVER TIGHTEN.
HARDWARE FOR STEP #3:
(AA) 1/4" X 1-3/4" BOLT = 8 PCS
LOCK WASHER = 8 PCS
PLAIN WASHER = 8 PCS
ALLEN WRENCH = 1 PC
DETAIL F
(DD)
