Track; Plotting Own Ship's Track - Furuno FAR-28x7 Series Operator's Manual

5.9

Track

5.9.1

Plotting own ship's track

A total of 6,000 points are allotted for storage of own ship's track, marks and
lines. When this memory becomes full, the oldest track is deleted to make room
for the latest. For that reason you may want to adjust the recording interval to
conserve the memory.
The table below shows the relation between plotting interval and maximum track
recording time.
Interval
10 s
30 s
1 min
1. Roll the trackball to choose the MENU box at the right side of the screen and
then push the left button.
2. Roll the wheel to choose 5 PLOTTER and then push the wheel.
1 BACK
2 CHART COLOR*
3 OWN TRACK INTERVAL
4 OWN TRACK COLOR
5 TGT TRACK INTERVAL*
6 TGT TRACK COLOR*
7 CURSOR L/L ALIGN
8 [DATA ERASE]
9 [DISPLAY]
0 AUTO TARGET TRACK*
3. Roll the wheel to choose 3 OWN TRACK INTERVAL and then push the
wheel or the left button.
4. Roll the wheel to choose appropriate option and then push the wheel or the
left button. Choose OFF to stop plotting own ship's track. DRAW displays the
track but does not record it.
5. Push the right button twice to close the menu.
Own track plotting interval and storage time
Max. Recording Time
55 hr 30 min
166 hr 40 min
13 days 21 hr 20 min
[PLOTTER]
GRN/YEL/CYA
ORANGE/GRAY
OFF/DRAW/10S/30S/
1M/2M/3M/6M/15M
RED/GRN/BLU/YEL/
CYA/MAG/WHT
OFF/DRAW/10S/30S/
1M/2M/3M/6M/15M
RED/GRN/BLU/YEL/
CYA/MAG/WHT
OFF/ON
OFF/ON
5. VIDEO PLOTTER OPERATION
Interval
2 min
3 min
6 min
* Not available on IMO type
PLOTTER menu
Max. Recording Time
27 days 18 hr 40 min
41 days 16 hr
83 days 8 hr
5-13
