Installation Manual
TABLE OF CONTENTS
SAFETY INSTRUCTIONS....................... i
EQUIPMENT LISTS .............................. iii
SYSTEM CONFIGURATION .................. v
1. MOUNTING ..................................... 1-1
1.1 Antenna Unit ........................................ 1-1
1.2 Monitor Unit.......................................... 1-8
1.3 Power Supply Unit ............................. 1-12
1.4 Control Unit ........................................ 1-13
1.5 Processor Unit ................................... 1-18
2. WIRING ........................................... 2-1
2.1 Interconnection .................................... 2-1
2.2 Antenna Unit ........................................ 2-2
2.3 Monitor Unit.......................................... 2-7
2.4 Processor Unit ..................................... 2-8
2.5 Power Supply Unit ............................. 2-12
Processor Unit .................................. 2-12
3. SETTING AND ADJUSTMENT ....... 3-1
3.1 DIP Switch Setting ............................... 3-1
3.2 Initializing Tuning ................................. 3-2
3.3 Heading Alignment............................... 3-3
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
MARINE RADAR/ARPA
FAR-2137S/2837S/2137S-BB
3.4 Adjustment Sweep Timing .................... 3-6
3.5 Suppressing Main Bang ....................... 3-7
3.6 Other Settings ...................................... 3-8
EQUIPMENT........................................4-1
4.1 Gyro Converter GC-10 ......................... 4-1
4.2 Memory Card Interface Unit ................. 4-9
4.4 BNC Connector Converter ................. 4-15
4.5 Junction Box....................................... 4-16
5. INPUT/OUTPUT DATA ....................5-1
INSTALLATION MATERIALS,
ACCESSORIES, SPARE PARTS ....... A-1
OUTLINE DRAWINGS ....................... D-1
INTERCONNECTION DIAGRAM ....... S-1
www.furuno.co.jp
Comply with MSC.192(79)
(non IMO-type only) .......................... 3-16
connection)........................................ 4-12
Back
Advertisement
Table of Contents
Related Manuals for Furuno 2137S
Summary of Contents for Furuno 2137S
-
Page 1: Table Of Contents
3.2 Initializing Tuning ... 3-2 3.3 Heading Alignment... 3-3 All brand and product names are trademarks, registered trademarks or service marks of their respective holders. MARINE RADAR/ARPA FAR-2137S/2837S/2137S-BB Comply with MSC.192(79) 3.4 Adjustment Sweep Timing ... 3-6 3.5 Suppressing Main Bang ... 3-7 3.6 Other Settings ... - Page 2 Nishinomiya, 662-8580, JAPAN Telephone : +81-(0)798-65-2111 : +81-(0)798-65-4200 Printed in Japan All rights reserved. Pub. No. IME-35210-L (HIMA ) FAR-2137S/BB/2837S The paper used in this manual is elemental chlorine free. ・FURUNO Authorized Distributor/Dealer A : APR L : APR . 12, 2011...
-
Page 3: Safety Instructions
Note: If the antenna unit is installed at a close distance in front of the wheel house, your administration may require halt of transmission within a certain sector of antenna revolution. This is possible. Ask your FURUNO representive or dealer to provide this feature. Model... - Page 4 WARNING Do not open the equipment unless totally familiar with electrical circuits and service manual. Only qualified personnel ELECTRICAL should work inside the SHOCK equipment. HAZARD Construct a suitable service platform from which to install the antenna unit. Serious injury or death can result if some- one falls from the radar antenna mast.
-
Page 5: Equipment Lists
220 VAC 3φ 60 Hz 380 VAC 3φ 50 Hz, 440 VAC 3φ 60 Hz 220 VAC, 3φ, 50 Hz 220 VAC, 3φ, 60 Hz 440 VAC, 3φ, 60 Hz For FAR-2137S For FAR-2837S For FAR-2137S For FAR-2837S AC type Standard type... - Page 6 Name RU-1803 RU-3305 Transformer Unit RU-5693 RU-6522 RU-5466-1 Memory Card Interface Unit CU-200-FAR External Buzzer OP03-21 Control Unit RCU-016 RAM Card 00RAM08MC-005 DVI-RGB Conversion Kit OP03-180-1 OP03-180-2 OP03-180-3 OP03-180-4 XH10P-W-6P L=20M XH10P-W-6P L=30M XH10P-W-5P-A L=10M XH10P-W-5P-A L=20M Cable Assy. XH10P-W-5P-A L=30M DVI-D/D S-LINK 10M S03-9-5 S03-9-10...
-
Page 7: System Configuration
: Option : Dockyard supply *: For FAR-2137S-BB, a monitor unit is prepared by user. See page 1-8. These monitors have been approved by the IMO, MU-190/201CR for CAT2, MU-231/231CR for CAT1. If a different monitor is to be used, its effective... - Page 8 Refer to the table shown below to confirm your category. Category FAR-2817, FAR-2827, FAR-2837S, FAR-2827W, CAT 1 FAR-2837SW CAT 1H FAR-2817, FAR-2827, FAR-2837S FR-2117/BB, FAR-2127, FAR-2127-BB, CAT 2 FAR-2137S, FAR-2137S-BB FAR-2117, FAR-2117-BB, FAR-2127, CAT 2H FAR-2127-BB, FAR-2137S, FAR-2137S-BB Radar Type Antenna rotation speed Normal speed Normal speed...
-
Page 9: Mounting
1. MOUNTING Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors. Antenna Unit Mounting considerations The antenna unit is generally installed either on top of the wheelhouse, on the radar mast, or on a suitable platform. - Page 10 1. MOUNTING • Install the antenna unit safely away from interfering high-power energy sources and other transmitting radio antenna. • Keep the lower edge of the antenna unit above the safety rail by 500 mm or more. • Two antenna units should be mounted as below: •...
- Page 11 Installation precaution for S-band antenna unit If an S-band antenna unit is mounted near the end of a platform to provide sufficient rotation clearance for the radiator, the antenna unit, because of its weight, swings up and down by ship’s vibration and rolling. This exerts excessive levels of stress at the base of the radiator, which can damage the radiator.
- Page 12 1. MOUNTING Antenna unit assembling The antenna radiator and the antenna housing are shipped in separate packages. Assemble them as below. The antenna unit may be assembled before hosting it to the mounting platform. However, do not lift the antenna unit by the radiator. Antenna unit assembling procedure 1.
- Page 13 How to lift the antenna unit 1. Fix the antenna radiator to the antenna unit chassis as shown on page 1-4. 2. Attach the lifting fixtures and collars as shown below. 3. Position the radiator as shown below and arrange the ropes A and B. Lifting hook (2 pcs.) Attachment of lifting fixtures, collar and ropes Lifting fixture...
- Page 14 1. MOUNTING Fastening the antenna unit to the mounting platform See the figure on the next page for antenna unit mounting. 1. Referring to the antenna outline drawing, drill eight fixing holes of 15 mm in diameter in the radar mast platform or the deck. The diameter of the mast for fixing the antenna unit platform must be over 250 mm.
- Page 15 Ground terminal Hex bolt Flat washer Ground wire Spring washer Hex nut Coat with silicone sealant. Ground wire Hex nut Spring washer Hex bolt Welding Arrange ground terminal as close as possible to antenna unit. G1_1/4-A Set corrosion-proof rubber mat, bolt antenna unit to mounting location, and coat exposed hardware with silicone sealant.
-
Page 16: Monitor Unit
The monitor unit can be flush mounted in a console panel, or mounted on a desktop using the optional accessories. For MU-190/231, see the applicable Operator’s Manual(s). Note: FAR-2137S-BB has no monitor unit. Prepare a suitable one locally. Recommended monitor: SXGA (1280x1024), aspect ratio 5:4... - Page 17 Desktop mounting Use the optional accessories to mount the monitor unit on a desktop. For FAR-2137S: FP03-09820 (Code No.: 008-535-560) For FAR-2837S: FP03-09830 (Code No.: 008-536-020) 4-FIXING HOLES 506 ± 1...
- Page 18 M12 bolts for fixing (Torque 63.5Nm) (Dockyard supply) Hanger stay Panel cover To remove this, insert fingernail in groove. Monitor Unit Remarks For FAR-2137S For FAR-2837S Hanger (R) Plastic rivet Flat Washer M10 Spring Washer M10 Hex bolt M10x30 (Torque 36.5Nm)
- Page 19 The hand grip is optionally available for the desktop mounting monitor unit. Hood (option) When it is too bright in the daytime, use the optional hood to shade the screen. For FAR-2137S: FP03-11500 (Code No.: 001-020-090) For FAR-2837S: FP03-11000 (Code No.: 008-571-680) Name...
-
Page 20: Power Supply Unit
1. MOUNTING Power Supply Unit The Power Supply Unit PSU-007 does not contain usual operating controls. Therefore, it can be installed in any recessed place either in vertical or horizontal position. (For the console mount display unit, the PSU-007 can be installed inside the console.) However, select a dry and well-ventilated location and observe the compass safe distance to prevent deviation of a magnetic compass. -
Page 21: Control Unit
Control Unit The control unit may be mounted on a tabletop, with or without the KB fixing metal (supplied), which mounts the control unit at an angle. Mounting considerations When selecting a mounting location, keep in mind the following points: Select a location where the control unit can be operated conveniently. - Page 22 1. MOUNTING Fixing without KB fixing metal 1. Drill four mounting holes of 5 mm diameter referring to the outline drawing at the back of this manual. 2. Fix the control unit with four screws (M4) from under side of the tabletop. (The M4 screws with a sufficient length for the thickness of the tabletop should be provided locally.) Flush mounting...
- Page 23 1. MOUNTING 1. Prepare a cutout in the mounting location as shown in the figure below. ±2 170±2 ±2 ±2 For RCU-014 For RCU-015 and RCU-016 2. Set the control unit to the cutout. 3. Attach the mounting plate to the control unit with four screws from the rear side. 4.
- Page 24 1. MOUNTING To connect RCU-016 in series with RCU-014 1. Pass the cable derived from RCU-016. 2. Connect the connector of the cable to J502. 3. Clamp the copper part of the cable with the cable clamp. Inside of RCU-014 1-16...
- Page 25 To change the cable entry To change the cable entry from the side (default) to the bottom, modify the unit as shown below. Screw M3X8 (Torque 0.78Nm) 3. Pass the cable from this hole. 4. In here, clamp the copper part of the cable with the cable clamp removed at step1.
-
Page 26: Processor Unit
1. MOUNTING Processor Unit Mounting considerations When selecting a mounting location, keep in mind the following points: Locate the processor unit away from heat sources because of heat that can build up inside the cabinet. Locate the equipment away from places subject to water splash and rain. Leave sufficient space at the sides and rear of the unit to facilitate maintenance. -
Page 27: Wiring
2. WIRING Wiring consideration • To lessen the chance of picking up electrical interference, avoid where possible routing the signal cable near other onboard electrical equipment (radars, transmitting radio antennas, etc.) Also avoid running the cable in parallel with power cables. When crossing with other cable, the angle should be 90°to minimize the magnetic field coupling. -
Page 28: Antenna Unit
2. WIRING Antenna Unit Gland for power cable 1. Open the right side cover on the antenna unit with the hex wrench. 2. Unfasten the cable gland for the signal cable and remove the gasket, flat washers and blind lid. 3. - Page 29 Pass the signal cable RW-9600. 6. Confirm that armor is grounded between two flat washers. 7. Coat the screw part of the clamping gland with silicone sealant and tighten it. 8. Using the opener, insert each core (except coaxial cable) to appropriate connector plug on the TB801.
- Page 30 2. WIRING Fabricating power cable TPYCY-2.5 1. Open the left side cover on the antenna unit with the hex wrench. 2. Fabricate the cable as shown below. Use TPYCY-2.5 (Japan Industry Standard) cable or equivalent. Approx. 170 mm 25 mm 5 mm Anti-corrosive Armor...
- Page 31 Terminal board for power cable Connect crimp-lug to the terminal block referring to the interconnection diagram. 9. Attach the cover (torque: 7.65 N·m). 10. Seal the cable gland with putty. Antenna unit, left view 2. WIRING Pass the power supply cable here.
-
Page 32: Monitor Unit
2. WIRING Monitor Unit Two cables are terminated at the display unit: the signal cable from the processor unit (5 m or 10 m cable) and the power cable from the ship’s mains. The signal cable comes with a connector preattached to it for connection to the display unit. Fabricate the power cable as below. -
Page 33: Processor Unit
Processor Unit Four cables are terminated at the processor unit: the antenna unit cable, display unit cable, control unit cable and the power cable. Cables other than the power cable come with a connector preattached to them for connection to the processor unit. Fabricate the power cable as below. - Page 34 2. WIRING Connection of cables The power cable is connected to the terminal board on the rear panel and the signal cable from the Monitor unit is connected to the DVI-D connector. Other cables are connected to the printed circuit board 03P9342. Monitor unit Network Power cable...
- Page 35 Location of connectors Open the processor unit as follows and the 03P9342 board appears. 03P9342 J621 External alarm J620 Track control J619 ECDIS Sub display* (SEMI-LOG) Sub display* (FULL-LOG) Master radar J614 + 12 V for card I/F J613 *: See page 2-11 for details. Cable clamp J608 J612...
- Page 36 2. WIRING Cable fabrication for the cables connected to the 03P9342 board Signal cable RW-9600 (Between antenna unit and processor unit) Vinyl sheath Vinyl tape Clamp here by cable clamp. Other cables for optional units Use TTYCS-1 or TTYCS-4 (Japan standard cable) or equivalent. 10.1 mm Conductor S = 0.75 mm...
- Page 37 Connection of Sub-display A conventional remote display and/or FAR-2107 series radar can be connected to J617 and J618 in the processor unit as a sub-display. However, the control for GAIN and STC are different depending on J617 and J618. Refer to the table to connect sub-displays. Port J617 Overall gain...
-
Page 38: Power Supply Unit
2. WIRING Power Supply Unit Wire the unit as shown in the interconnection diagram. Thermal relay K2: Connect input line. TB1: Connect control line. Changing AC Power Specification of Processor Unit To change AC power specification between 100 VAC and 220 VAC, add or remove jumper connector P108 on the PWR board 03P9339 and change the fuse on the processor unit according to ship’s mains as shown in the table below. - Page 39 Upper part of processor unit (SPU assembly omitted) PWR board (OVER) P108/J108 8 7 6 5 4 3 2 1 Jumper connector (VH8P) How to adjust the overvoltage detection circuit: 1. Add or remove the jumper connector P108 and change the fuse. 2.
- Page 40 2. WIRING This page is intentionally left blank. 2-14...
-
Page 41: Setting And Adjustment
3. SETTING AND ADJUSTMENT DIP Switch Setting The processor unit is shipped for model FAR-2137S. If your model is FAR-2837S/2137S-BB, change the DIP switch setting as follows. 1. Remove the top cover of the processor unit. 2. Open the SPU assembly block and remove the shield cover. -
Page 42: Initializing Tuning
3. SETTING AND ADJUSTMENT Initializing Tuning 1. Transmit the radar on 48 nm range and rotate the GAIN knob to show 70-80 of the gain bar. 2. Roll the trackball to choose the MENU box at the right side of the screen and then push the left button. -
Page 43: Heading Alignment
Heading Alignment You have mounted the antenna unit facing straight ahead in the direction of the bow. Therefore, a small but conspicuous target dead ahead visually should appear on the heading line (zero degrees). In practice, you will probably observe some small bearing error on the display because of the difficulty in achieving accurate initial positioning of the antenna unit. - Page 44 3. SETTING AND ADJUSTMENT 7. Press [0] key to show the [INITIALIZE] menu. Note: See next page to access the INITIALIZE menu with the trackball style control unit RCU-015. 8. Press [2] key to open the [ECHO ADJ] menu. 9. Press [3] key to choose the HD ALIGN option. 10.
- Page 45 How to Access the Installation Mode with the RCU-015 Trackball Style Controller 3. SETTING AND ADJUSTMENT 1. By using the trackball, move the pointer until it highlights the MENU box as shown. DO NOT CLICK the menu box, just leave the arrow over the menu.
-
Page 46: Adjustment Sweep Timing
3. SETTING AND ADJUSTMENT Adjustment Sweep Timing Sweep timing differs with respect to the length of the signal cable between the antenna unit and the processor unit. Adjust sweep timing at installation to prevent the following symptoms: • The echo of a “straight” target (for example, pier), on the 0.25 m range, will appear on the display as being pulled inward or pushed outward. -
Page 47: Suppressing Main Bang
Suppressing Main Bang If main bang appears at the screen center, suppress it as follows. 1. Transmit the radar on a long range and then wait ten minutes. 2. Adjust gain to show a slight amount of noise on the display. 3. -
Page 48: Other Settings
3. SETTING AND ADJUSTMENT Other Settings ECHO menu setting Open the [ECHO ADJ] menu as described on page 3-2. To close the menu, press the [MENU] key. CABLE ATT ADJ Before adjusting, set the radar as follows: IR: 2, ES: off, EAV: off, 24nm range, long pulse (Same as default setting of PICTURE1) To adjust the cable attenuation manually, choose MANUAL by pressing [2] and the [ENTER] key, and then rotate the wheel so that noise just appears on the screen when the gain is set... - Page 49 0 for both the START and ANGLE sections. The setting range of START is 0 to 359 and ANGLE is 0 to 180 . ANT REVOLUTION Not used for FAR-2137S/2837S/2137S-BB. ANT SW and ANT STOPPED This is used for antenna maintenance by serviceman.
- Page 50 Confirm the model of your radar. If the setting of this item is different from your model (combination of the antenna unit), the radar functions abnormally. Select “30 UP” for FAR-2137S/ 2837S/ 2137S-BB. TYPE Choose type of radar: IMO, A, B, C, or W.
- Page 51 ON TIME and TX TIME These items show number of hours the radar has been turned on and transmitted, respectively. Value can be changed; for example, after replacing magnetron TX Time can be reset to 0. PM GAIN ADJ When you choose this item, the radar setting changes as follows. RANGE: 24 NM PULSE:...
- Page 52 3. SETTING AND ADJUSTMENT OWN SHIP INFO menu setting Open the OWN SHIP INFO menu by pressing [5] key on the INITIALIZE menu. LENGTH/WIDTH and SCANNER POSN To inscribe own ship shape on the screen when you choose it on the menu, enter length and width of the ship and antenna position from the bow and left sides.
- Page 53 TT PRESET menu setting Open the TT PRESET menu by pressing [6] key on the INITIALIZE menu. [TT PRESET] 1 BACK 2 TT DATA OUTPUT OFF/TTM/TTD REL/TRUE 4800/9600/ 19200/38400 3 MAX RANGE 24/32 4 ECHO LEVEL 5 QV DISPLAY OFF/ON 6 TT W/O GYRO* OFF/ON 7 [TT PRESET]...
- Page 54 3. SETTING AND ADJUSTMENT TT W/O GYRO (Not on IMO radar) If a gyrocompass is not connected, choose the TT function, ON(working) or OFF (no working). LAND SIZE Set the land size in units of 100 m. The setting range is 100 to 1000 m. ANT SELECT Set the antenna radiator type of your radar.
- Page 55 OTHER menu setting Open the OTHER menu by pressing [8] key on the INITIALIZE menu. EAV w/o GYRO If a gyrocompass is not connected, choose the echo average function, ON (working) or OFF (no working). TT CATEGORY SELECT Choose CAT1 or CAT2▪3 depending on your ship size. CAT1: All ships over than 10,000 GT CAT2: All ships between 500 and 10,000 GT CAT3: All ships less than 500 GT...
-
Page 56: Dual Radar Display (Non Imo-Type Only)
3. SETTING AND ADJUSTMENT Dual Radar Display (non IMO-type only) The image from two or more radars may be shown together on one radar display. This allows you to take advantage of the best characteristics radars has to offer. Image from main radar Image from external radar The following should be done in order to enable the dual radar display:... - Page 57 Note 2: In the dual radar display, a guard zone set on the main radar is also accommodated on the external radar. When the position of the antennas for the main and external radars is different and the No. 2 guard zone is set on a close-in range, the on-screen guard zone may be shifted slightly from both the main radar antenna reference and external radar antenna reference.
- Page 58 3. SETTING AND ADJUSTMENT Push the right button four t imes to close the menu. Note 1: The dual radar function becomes inoperative when the external radar is turned off, set to stand-by, or set as sub display. When this happens, the buzzer sounds and the message "EXT RADAR STBY"...
-
Page 59: Specifying Sector Width And Length
3.7.2 Specifying Sector Width and Length When 2 DUAL RADA R in the DUAL RADAR menu is set for "COMBINE", specify the width and length o f the sector from the external radar to display on own radar. 1. Open the INITIALIZE menu. 2. - Page 60 3. SETTING AND ADJUSTMENT 7. Use the scrollwheel to set START and ANGLE, referring to the description and example below. Spin the scrollwheel to set and push it to confirm. c) A solid green line marks the dual radar display area. START: Start point of the sector (in degrees, 000-359) ANGLE: Width of the sector (in degrees, 000-359) d) In the example below, START is 130°...
- Page 61 3.7.3 Choosing External Radar (image source) Select the external radar to use in the dual radar display. 1. Open the INITIALIZE menu. 2. Press the [3] key to show the SCANNER menu. 3. Select 9 [DUAL RADAR] and push the left button. 4.
- Page 62 3. SETTING AND ADJUSTMENT This page is intentionally left blank. 3-22...
-
Page 63: Installing Optional Equipment
4. INSTALLING OPTIONAL EQUIPMENT Gyro Converter GC-10 The Gyro Converter GC-10, incorporated inside the processor unit, converts analog gyrocompass reading into digital coded bearing data for display on the radar screen. This section explains how to install the GC-10 (mainly consisting of the GYRO CONVERTER board) and set it up according to gyrocompass connected. - Page 64 4. INSTALLING OPTIONAL EQUIPMENT 2. Fasten the GYRO CONVERTER board in the processor unit with five washer head screws and male connector 231-607/019-FUR (called J602) with two screws. Screw M3X8 5 pcs (Torque 0.78Nm) Attaching GYRO CONVERTER board in the processor unit 3.
- Page 65 4. Connect the GYRO CONVERTER board and J602 with two connector assemblies 03-2089 and 03-2090. Connection for J602 From J4 From J5 VH connector assy. 03-2089 (5P) VH connector assy. 03-2090 (3P) 4. INSTALLING OPTIONAL EQUIPMENT Wiring for WAGO connector Press downward.
- Page 66 4. INSTALLING OPTIONAL EQUIPMENT 5. Confirm gyrocompass specifications and set up the DIP switches and jumper wires on the GYRO CONVERTER board according to gyrocompass connected: Setting jumper wires and DIP switches by gyrocompass specifications: page 4-5 Setting jumper wires and DIP switches by make and model of gyrocompass: page 4-7 Location of jumper wires and DIP switches: page 4-8 6.
- Page 67 Connection of external power supply An external power supply is necessary when the repeater signal is step-by-step type and the step voltage is below 20 V or output voltage is less than 5 W. 1. Cut jumper wire JP1 on the GYRO CONVERTER board when an external power supply is used.
- Page 68 4. INSTALLING OPTIONAL EQUIPMENT Setting method 1: DIP switch settings and gyrocompass specifications 1) Gyrocompass type Gyrocompass type synchronous synchronous DC step Full-wave pulsating current Half-wave pulsating current 3) Rotor Voltage (between R1 & R2) Rotor Voltage 20 to 45 VAC 30 to 70 VAC 40 to 90 VAC 60 to 135 VAC...
- Page 69 Setting method 2: by make and model of gyrocompass a t l a t l a t l a t l ) - ( i a l a t l a t l CMZ-700 DC step 24V 180x COM(+), 3-wire(-) ) - ( a t l a t l...
- Page 70 4. INSTALLING OPTIONAL EQUIPMENT Location of DIP switches, jumper wires on the GYRO CONVERTER board (Rotor voltage) (Stator voltage) (Gyro type) Fuse (2A) (Stator signal input) (Rotor signal input, external power input) Setting the heading readout on the radar display Confirm that the gyrocompass is giving a reliable readout.
-
Page 71: Memory Card Interface Unit
Memory Card Interface Unit Mounting considerations When selecting a mounting location, keep in mind the following points: Locate the memory card interface unit away from heat sources because of heat that can build up inside the cabinet. Locate the unit away from places subject to water splash and rain. Leave sufficient space at the sides and rear of the unit to facilitate maintenance. - Page 72 4. INSTALLING OPTIONAL EQUIPMENT Desktop mount For desktop mount, the optional desktop mount kit FP03-10201 is required. Refer to the end of this manual. 1. Fix the mounting bracket 19-023-3081 on the unit with four screws. 2. Mount the above assembly on a desktop with four tapping screws. Console mount For console mount, the optional console mount kit FP03-10202 is required.
- Page 73 MJ-A3SPF0015-100 (10 m) No.1 J614 Processor unit FR-FTPC-CY (10/20/30 m) (straight) NETWORK FR-FTPC-CY No.2 (10/20/30 m) Processor (straight) unit No.3 Processor FR-FTPC-CY (10/20/30 m) (straight) unit No.4 FR-FTPC-CY (10/20/30 m) (straight) Processor unit Note: When two memory card interface units are connected via network, change ID code for the second unit.
-
Page 74: Dvi-Rgb Conversion Kit (For Vdr Connection)
4. INSTALLING OPTIONAL EQUIPMENT DVI-RGB Conversion Kit (for VDR connection) This information provides the procedure necessary for the installation of the DVI-RGB conversion kit. This kit is installed in the processor unit to enable connection of a VDR (Voyage Data Recorder) or RGB monitor to record radar pictures into a VDR. When changing the D-sub 15P of the RGB cable to the BNC connector, use the BNC connector converter described on page 4-15. - Page 75 Remove the top cover and open the upper part of the processor unit. 2. Fix the 03P9229A board (RGB-BUFF) with four screws. (See the figure below.) 3. Attach the connector assemblies to J1 and J3 on the 03P9229A board as follows. J1：13-pin connector of the connector assembly 03-2094 J3：3-pin connector of the connector assembly 03-2093 4.
- Page 76 4. INSTALLING OPTIONAL EQUIPMENT DVI-RGB Conversion board Fixing the DVI-RGB conversion board 6. Attach the 10-pin connector from J1 on the 03P9229A board to J9 on the DVI-RGB board. 7. Attach the connector assembly 03-2092 to J4 on the DVI-RGB conversion board. 8.
-
Page 77: Bnc Connector Converter
4.4 BNC Connector Converter To connect the VR-5000 (FURUNO Voyage Data Recorder) to this radar, the DVI-RGB conversion kit (mentioned at previous paragraph) and the BNC connector converter are required. Also VGA cable (between the processor unit and the BNC connector converter) and five 75 ohms coaxial cables (between the BNC connector converter and VR-5000) are required. -
Page 78: Junction Box
4. INSTALLING OPTIONAL EQUIPMENT 4.5 Junction Box Junction Box If the length of the antenna cable is more than 100 m, the optional junction boxes are required. These boxes should be mounted at the location protected because its waterproofing is IPX3. Antenna unit RW-9600 (Max 15 m) - Page 79 Cable fabrication RW-9600 Vinyl sheath DPYC-6 and TTYC-4 DPYC-6: approx. 130 TTYCY-4: approx. 150 Armor Taper for unused wires. Vinyl sheath RG-12/UY Vinyl sheath 4. INSTALLING OPTIONAL EQUIPMENT approx. 450 Shield Armor Pull out inner cables from here. 14 5 9 Shield Coaxial cable Crimp on lug for M8...
- Page 80 4. INSTALLING OPTIONAL EQUIPMENT Connection Insert each cable to the cable gland as follows. Cable gland Flat washer Vinyl sheath Gasket Clamping gland Cut and trim armor. Connect each cable cores to the terminal board, referring to the interconnection diagram on next page.
- Page 81 Antenna unit Junction box 03P9349 RW-9600 TB801 TX-HV N.C. RED[B] ORG[B] 24V_PLUS YEL[B] 24V_MINUS BLU[B] GLY[B] PPL[B] WHT[B] SPU_RF_D_A SPU_RF_D_B RF_SPU_D_A RF_SPU_D_B GRN[B] SIG-GND TB802 COAX IF_VIDEO Clamp with cable-gland. 4. INSTALLING OPTIONAL EQUIPMENT Junction box DPYCY-6 DPYCY-6 N.C. N.C. TTYCY-4 N.C.
- Page 82 4. INSTALLING OPTIONAL EQUIPMENT This page is intentionally left blank. 4-20...
-
Page 83: Input/Output Data
5. INPUT/OUTPUT DATA Input and output data are shown in the table below. Note: This radar accepts position data fixed by WGS-84 geodetic datum only. Set the datum to WGS-84 on the EPFS (GPS, etc.) connected to this radar. If other type of datum is input, the error message "DATUM"... - Page 84 5. INPUT/OUTPUT DATA IEC 61162 input sentence and priority Contents Speed (STW) Speed (SOG) Speed (position) Heading (True) Position Datum Waypoint Route Date, Time Depth Temperature Wind Set and Drift ALARM ACK IEC 61162 output sentence Contents Target L/L Radar system data Own ship data TT target data ALARM data...
- Page 103 May 17'07 R.Esumi...
- Page 110 D-10...
- Page 111 D-11...
- Page 112 D-12...
- Page 113 D-13...
- Page 114 D-14...
- Page 115 D-15...
- Page 116 D-16...
- Page 117 D-17...
- Page 118 D-18...
- Page 119 D-19...
- Page 120 D-20...
- Page 121 D-21...
- Page 122 D-22...
-
Page 123: Interconnection Diagram
RS-232C 制御部 PROCESSOR UNIT RPU-013 +12V +12V DVI-D/DSINGLELINK5M/10M RGBﾋﾞﾃﾞｵｺﾝﾊﾞｰﾀ 5/10m,φ7 RGB VIDEO CONVERTOR DVI-RGB-1 -5/-12V 表示部 MONITOR UNIT MU-190/201CR (FAR-2137S) MU-231/231CR (FAR-2837S) 保護アース *1 *5 IV-8sq. トランス TRANSFORMER RU-1803 保護アース PE *1 *5 IV-8sq. ｽｲｯﾁﾝｸﾞ ﾊﾌﾞ 防水型ｶｰﾄﾞｲﾝﾀｰﾌｪｲｽ SWITCHING HUB MEMORY CARD I/F UNIT...
