Matrix Software, cont'd

Optimizing the Video

Each TP input has a level and peaking adjustment. Most MTP transmitters and half
of the MTPX Plus TP outputs have a pre-peaking feature. TP inputs and outputs
have skew adjustments. Set these adjustable features as follows for the best image
quality:
N For all of the settings in this section (with the exception of the transmitter's
N Unless the TP cables are changed, these adjustments should need to be made
Before you start optimizing, set all input level and peaking, input and output
skew, and output pre-peak settings to either zero or off.

MTP transmitter Pre-Peak selection

For inputs from MTP T 15HD products only — If the cable between the MTP
transmitter and the MTPX Plus is > 300', turn the transmitter's Pre-Peak switch on.
For shorter cables, turn the switch off.

MTPX level/peaking setting

The simplest and surest way to set the input level/peaking is to use the included
MTP signal generator and the Auto-calibration utility within the Matrix Switchers
Control Program as follows:
N To manually set the input level/peaking, proceed to step 8.
1.
2.
3.
Figure 5-20 — MTP signal generator
4.
5.
5-24 MTPX Plus Twisted Pair Matrix Switchers • Matrix Software
Pre-Peak switch in step 1), see the MTPX Pictures settings and MTPX
configuration settings menu items in "Tools menu", on page 5-19.
These settings can also be made using SIS commands or the built-in HTML
pages. See chapter 4, "Programmer's Guide" and chapter 6, "HTML
Operation".
only once, during installation.
Disconnect the power and RJ-45 cables at the MTP transmitter connected to
the input to be adjusted.
Connect the two cables to the included MTP signal generator.
If the input cable between the transmitter and the MTPX Plus is longer than
300' (90 m), place the MTP signal generator's Pre-Peak switch on (figure 5-20).
Pre-Peak on (up) (shown)
Power LED Pre-Peak off (down)
In the Matrix Switchers Control Program, click Tools > MTPX Picture settings
to open the MTPX Picture Settings window (figure 5-16 on page 5-20).
Click the Auto-Calibrate Level/Peaking button.
After a few moments, the program reports whether or not the
calibration succeeded and the original and new settings for the
input Pre-Peaking adjustment.
