22 Installing the Cross-Connect Panel
Table 8-A
COLOR CODES FOR THE LANLINK CABLES
PAIR No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Practice 450-1011-201
COLOR CODE
White/Blue
White/Orange
White/Green
White/Brown
White/Slate
Red/Blue
Red/Orange
Red/Green
Red/Brown
Red/Slate
Black/Blue
Black/Orange
Black/Green
Black/Brown
Black/Slate
Yellow/Blue
Yellow/Orange
Yellow/Green
Yellow/Brown
Yellow/Slate
Yellow/Blue
Yellow/Orange
Yellow/Green
Yellow/Brown
Yellow/Slate
