138 How to Connectorize Cables
Figure 16-3
CERTI-CRIMP Tool, AMP 90312-1
For Terminating 15-Pin DTL SRU Connectors
Locator
Anvil
Jaws
Back of
Tool
(Wire side)
Practice 450-1011-201
Contact
Locator
Crimper
Jaws
AMP
Ratchet
Crimper
Jaws
View B
Front
of Tool
Anvil
Jaws
View A
Cushioned
Hand
Grips
Wire Stop
Wire Stop
Slot
(In contact)
View C
Blue
28 - 24
24 - 20
Red
Crimp Section
Wire Size
Markings
