Figure 16-2
AMP CHAMP T-Handle Insertion Tool, 229384-1
For Inserting Single Wires Into Connectors
Cross Section of
Connector Block
Mating End
of Contact
Note: Female connector shown
Apply Approx. 15-lb. Pressure
End of Wire
Placement
Block or
Suitable
Support
How to Connectorize Cables 137
Wire
Blade
Wire Termination
End of Contacts
Practice 450-1011-201
