Table 15-B Continued
ALIU Options Settings
JUMPER STRAPPING OPTION
ALARM OUTPUT OPTIONS
J21 Pin 3 to Pin 2 (default)
Pin 1 to Pin 2
J22 Pin 3 to Pin 2 (default)
Pin 1 to Pin 2
J23 Pin 1 to Pin 2 (default)
Pin 3 to Pin 2
J24 Pin 3 to Pin 2 (default)
Pin 1 to Pin 2
J25 Pin 3 to Pin 2 (default)
Pin 1 to Pin 2
J26 Pin 1 to Pin 2 (default)
Pin 3 to Pin 2
J27 Pin 3 to Pin 2 (default)
Pin 1 to Pin 2
J28 Pin 3 to Pin 2 (default)
Pin 1 to Pin 2
J29 Pin 1 to Pin 2 (default)
Pin 3 to Pin 2
Installing the Alarm System 131
FUNCTION
Auxiliary 2 relay contact closure
Auxiliary 2 relay contact opening
Auxiliary 1 relay contact closure
Auxiliary 1 relay contact opening
Bay contact closure
Bay contact opening
Minor visual contact closure
Minor visual contact opening
Major visual contact closure
Major visual contact opening
Critical visual contact closure
Critical visual contact opening
Minor audible contact closure
Minor audible contact opening
Major sudible contact closure
Major audible contact opening
Critical audible contact closure
Critical audible contact opening
