Installing the Cross-Connect Panel 3
Figure 7-1
Building Wiring and Equipment Layout
25-Pair LANlink Cables
3-Pair Cables
914 mm (36 in.) max.
(24 Gauge)
RJ11
Wall Jack
2-Pair Jumper Wires
M4000
LIU
To Host Computers,
ASCII Terminals,
Modems, Printers,
etc.
MDF or IDF (Universal BIX-PAC
Cross-Connect Panel
in Blue Field or 66-type, such as NE66QAB)
(optional)
Practice 450-1011-201
