Figure 13-2
Tape Head Location in the 1/4-shelf Disk/Tape SRU
The read/write heads are located behind
this knob, close to the back of the slot.
They are exposed slightly (for cleaning)
when this knob is pushed down.
Loading/Removing the Tape Cartridge (Cartridge SRU) 115
Push this knob down
to clean the tape heads
Practice 450-1011-201
