Northern Telecom DNC-50 Installation Manual page 112

(2) Run the RS-232-C cable from the terminal to the LIU (or modem, for remote
All wiring and cabling should be routed and secured according to local
building and safety codes.
(3) Connect the cable to the LIU (or modem) according to Fig. 12-2. Refer to the
(4) Tighten the two screws on the RS-232-C cable.
(5) Power up and verify the operation of the terminal according to the
Figure 12-2
Connecting an ASCII Terminal to an LIU
Teladapt
Connector
Connecting Peripherals, Hosts, and Modems to the LIU 105
to the terminal manufacturer's documentation for a description of the terminal's
RS-232-C port.
connections) according to the floor plan and wiring drawings.
provisioning tables for the port assignments.
manufacturer's documentation.
Note: The communications parameters of the terminal must be compatible with
those set for the communications link in System Administrative Services. The
system administrator sets up the parameters according to the Guide to System
Administrative Services, 450-1011-301.
3-Pair Twisted
Telephone Cable
- WARNING -
LAN
Interface
Unit
RS-232-C Cable
ASCII Terminal
Practice 450-1011-201
