Table 15-B
ALIU Options Settings
The default settings are the Pin1 to Pin2 connections in all cases up to J20, except for J3 and J10/J16.
J11 and J12 (Opto-coupler Input Voltage Options) are only used for systems with a 24 Vdc source or
reference the Battery Return on P2 and P4 of J11. The defaults for J11 and J12 are therefore OUT. If
the J11 or J12 defaults are to be changed, you must order the jumpers separately (order code
A0292488) and install them (maximum of nine jumpers).
J21 to J29 are used to control the alarm output signal. The default settings are:
pin 3 to pin 2 for J21, J22, J24, J25, J27, and J28
-
- pin 1 to pin 2 for J23, J26, J29.
The opposite settings for all of these pins result in alarm condition from a contact opening, i.e., loss of
signal.
JUMPER STRAPPING OPTION
ALARM CUT-OFF OPTIONS
J1 Pin1 to Pin2 (default)
Pin 3 to Pin 2
J2 Pin1 to Pin2 (default)
Pin 3 to Pin 2
J3 Pin1 to Pin2
Pin 3 to Pin 2 (default)
J6 Pin1 to Pin2 (default)
Pin 3 to Pin 2
OPTO-COUPLER INPUT SOURCE OPTIONS
J14, J15 Pin1 to Pin2 (default)
Pin 3 to Pin 2
J19, J20 Pin1 to Pin2 (default)
Pin 3 to Pin 2
J17, J18 Pin1 to Pin2 (default)
Pin 3 to Pin 2
J10, J16 Pin1 to Pin2 (not used)
Pin 3 to Pin 2
Installing the Alarm System 129
FUNCTION
Auxiliary 1 relay ACO enabled
Auxiliary 1 relay ACO disabled
Auxiliary 2 relay ACO enabled
Auxiliary 2 relay ACO disabled
Single command of visual and audible alarms,
including ACO
Separate commands for control of visual and audible
alarms, ACO alarms only
Bay alarm ACO disabled
Bay alarm ACO enabled
FAN1ALM inputs selected
AUXIN1 inputs selected
FAN2ALM inputs selected
AUXIN2 inputs selected
FUSEALM inputs selected
AUXIN3 inputs selected
Reserved for future use
USERIN1 inputs always selected
