Figure 4-10
Installing the Rear Door and Fan Cover
Push In
7)
(8)
Press Down
and Inward
Tilt the rear door outward at the top on a 45-degree slant without
disengaging it from the bottom hingepin as shown in Fig. 4-10.
Similarly tilt the bottom of the fan cover outward on a 45-degree slant so
that the hingepin hole on the bottom of the fan cover is positioned at the
top hingepin in the cabinet door.
Installing a -48 Vdc Power Distribution System 31
Practice 450-1011-201
