Altronix AL642ULADA Application Manual page 8

R1042ULADA Enclosure Dimensions (H x W x D):
3.25" x 19.0" x 26.5" (82.6mm x 482.6mm x 673.1mm). Shown with Z Bracket attached.
2.4"
61mm
4.57"
116.1mm
26.5"
673.1mm
3.25"
82.3mm
Altronix is not responsible for any typographical errors.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty
42ULADA Application Guide
- 8 -
11.175" (283.8mm)
1" (25.4mm)
0.55" (14mm)
R 1.27" (32.3mm)
19" (482.6mm)
H09U
0.1"
2.5mm
3.62"
92mm
42 ULADA Application Guide
1.5"
38.1mm
