Microchip Technology WFI32-IoT User Manual page 23

Figure 5-15. Ambient Light Sensor
3V3_IN
C414
R431
0.1uF
0R
16V
0402
0402
GND GND
Figure 5-16. Temperature Sensor
TDO/AN7/CVD7/CVDR7/CVDT0/RPB7
Figure 5-17. ICSP HDR
3V3_IN
GND
PGD2/AN5/CVD5/CVDR5/CVDT2/RTCC/RPB5
PGC2/AN4/CVD4/CVDR4/CVDT3/RPB4
©
2022 Microchip Technology Inc.
and its subsidiaries
R414
1.5k
0402
I2C address: 0x44 5%
U401
1 6
VDD SDA
2 5
ADDR INT
3 4
GND SCL
OPT3001DNPT USON-6
GND
3V3_IN
SDA1/RPA5
SCL1/RPA4
NMCLR
NMCLR
User Guide
Appendix A: Reference Circuit
3V3_IN
R413
R412
1.5k
10k
0402
0402
5%
1%
SDA1/RPA5
TMS/AN6/CVD6/CVDR6/CVDT1/RPB6
SCL1/RPA4
R419
100k
I2C address: 0x18
U402
1%
1
SDA VDD
2
SCL A0
3
Alert A1
4
GND A2
MCP9808
GND
0R
R429
DNP 0201
0201
R430
0R
DNP
EV36W50A
3V3_IN
8
7
6
C420
5
0.1uF
16V
0402
GND
J401
1
2
3
4
5
6
HDR-2.54 Male 1x6
DNP
DS50003262A-page 23
