Valve Installation

Valve must be installed at the gas inlet pipe, water inlet pipe, and water
outlet pipe. After the installation, checking must be done to make sure
that there is no gas or water leak.
Hot Water
Outlet

Preparation

1. Insert 2 pieces of battery. Make sure the positive and negative
poles of the battery are well-installed (not reversed).
2. Open the gas inlet and water inlet valves.

Turning On the Water Heater

When the water pressure is above 0.015 MPa, the water heater will be
turned on automatically if the hot water valve is opened. For the water
heater that is just installed, the gas pipe perhaps is filled with air and
cannot be turned on at the first time. Repeat the on and off process to
exhaust the air out until the water heater turns on.
Min
Max Max
Temperature
Drainage Pipe
Cover

PART 4: HOW TO USE

Min
Volume
Valve
9
Min Max
Gas Inlet
Water Inlet
