CyberData 011490 Installation Quick Reference page 2

Loudspeaker Amplifier Connections
Cover
Slide I2C Cable Grommet
Screw
Remove Hole Plug
into Cover Plate Slot
and Grommet
Cover
Plate
with IP66 Rating Enclosure
Remove Cord Grip Assembly
then Replace with
1/2" EMT Compression Connector
1/2" EMT Compression Connector
1/2" EMT Conduit
Strobe Cable Connection
© 2021, CyberData Corporation, ALL RIGHTS RESERVED
to
STROBE IN
Outdoor Auxiliary
Cable & Wire
Create Service Loop RGB Strobe
to J1 J1
Lock
Washer
Backbox Ground
Gasket
(Optional)
(Faceplate Ground)
Remove Hole Plug Assembly then
Install It onto Rear Conduit Hole
Keep Washer that
Came with the
1/2" EMT Compression Connector
1/2" EMT Compression Connector
Lock
Washer
931658C Quick Reference
Optional Conduit Wall Mounting (Outdoor Intercom or Outdoor Call Button)
Note: All parts shown are not provided
other than the 011490 Strobe Kit.
I2C
to JX
Auxiliary
Outdoor
RGB Strobe
Faceplate Mounting
Torx Security Screw
Network Cable
to J1
Outdoor
Intercom
OR
Outdoor
Call Button Ground Wires
to Ground Stud
Network Cable
to J1
Torx Key
Faceplate
Faceplate Mounting
Assembly
Torx Security Screw
Quick Reference
Hole Plug
Assembly
1/4" Concrete
Wall Anchor & Screw
Apply RTV
Silicone Sealant
Around Mounting Holes
Backbox
Spacer
1/2" EMT
Compression
Connector
Ground Wire
Ground Wire
to Ground Stud
on Faceplate
I2C Cable
I2C
to JX
Network Cable
1/2" EMT
1/2" EMT
Conduit
Compression
Connector
Ground Wire to
Speaker Stud
Apply RTV
Silicone Sealant
Around Backside Perimeter
Spacer
Network and Ground Wires in
Through Rear Conduit Hole
I2C
to JX
Backbox
to Ground Stud
on Faceplate
to Remove Hex Nut:
11/32" or 9mm
Open-End Wrench
or Socket
931658C © 2021, CyberData Corporation, ALL RIGHTS RESERVED
