CyberData 011490 Installation Quick Reference

Dimensions and Rear View with Mounting Holes
2.79 [71.0]
DIMENSIONS ARE IN INCHES [MILLIMETER]
© 2019, CyberData Corporation, ALL RIGHTS RESERVED
Mounting Hole
1/2" Conduit Hole
1.690 [42.9]
3.380 [85.9]
5.118 [130]
931658A Quick Reference
Installation Quick Reference
Auxiliary Outdoor RGB
The IP Endpoint Company
(Multi-Color) Strobe Kit
011490
Parts List
• (1) Auxiliary Outdoor RGB (Multi-Color) Strobe Kit
• (1) 3.28 feet [1 meter] cable
Features
• Meets ADA requirements for telephony signaling and notification
• Activates from a CyberData IP endpoint
• Mailbox Message Waiting Indication
• Multicast activation
Getting Started
• Download the Operations Guide PDF file, from the Downloads tab at the following
webpage:
https://www.cyberdata.net/products/011490
• Create a plan for the locations of your Auxiliary RGB (Multi-Color) Strobe Kits.
• WARNING: This product should be installed by a licensed electrician according to all local
electrical and building codes.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in
accordance with the installation instructions.
• WARNING: This enclosure is not rated for any AC voltages!
Parts
(1) T-15H Torx Key Optional Accessories
(1) Auxiliary RGB
(for gooseneck mounting)
(Multi-Color)
Strobe Kit
(4) Carriage bolt nuts
Assembly
(4) Security Torx Screw
(4) Carriage bolts
(4) Carriage bolt washers
Contacting CyberData
Corporate Headquarters
Sales: (831) 373-2601 ext. 334
CyberData Corporation
Support: 831-373-2601 ext. 333
3 Justin Court
Support Website:
Monterey, CA 93940, USA
RMA Department: (831) 373-2601 ext. 136
RMA Email: RMA@CyberData.net
Phone: 831-373-2601
Fax: 831-373-4193 RMA Status: http://support.cyberdata.net/
http://www.cyberdata.net/ Warranty Information:
Quick Reference
Optional Accessories
(1) Spacer for half-inch set conduit connector
(1) 531085* hole plug assembly
