V-ZUG Combair V200 Manual

V-ZUG Combair V200 Manual

Hide thumbs Also See for Combair V200:
Table of Contents

Advertisement

Quick Links

Download this manual
V-ZUG-Home
Install the app, network your appliances and
benefit from a wide range of useful functions.
Operating instructions
Combair V200
Oven • Cooker

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Combair V200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for V-ZUG Combair V200

Summary of Contents for V-ZUG Combair V200

  • Page 1 V-ZUG-Home Install the app, network your appliances and benefit from a wide range of useful functions. Operating instructions Combair V200 Oven • Cooker...
  • Page 2 55-762 CH2H57UKH3N/W, CH2H57UKH4N/W, CH2H57UTKH2N/W, CH2H57UTKH3N/W, CH2H57UTKH4N/W Combair V200 22018 CH2H660KH4N/W, 60-600 CH2H660TKH4N/W Combair V200 22023 CH2H57UKH4VN/W, 55-762 CH2H57UTKH4VN/W Combair V200 22024 CH2H660KH4VN/W, 60-600 CH2H660TKH4VN/W Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2021...

  • Page 3: Table Of Contents

    Selecting the cooking space temperature.. 13 13.4 Saving energy............  26 Switching off ............ 13 Disposal  27 Removing the cooked food from the cooking space .............. 13 Index  28 V-ZUG-Home  14 Notes  30 Conditions ............. 14 Service & Support  31 Initial set-up............ 14 User settings  15 V-ZUG-Home............ 15...

  • Page 4: Safety Precautions

    Safety precautions Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that...
  • Page 5 1 Safety precautions to touch the heating ele- ▪ Under no circumstances use ments. Children under 8 a steam cleaner to clean the years of age must be kept appliance. away from the appliance un- ▪ WARNING: Before replacing less they are constantly su- the light bulb, ensure the ap- pervised.

  • Page 6: Instructions For Use

    1 Safety precautions Note on use Instructions for use ▪ Use the childproof locking facility. Before using for the first time ▪ If the appliance is visibly damaged, do ▪ The appliance must be installed and not use it. Contact our Customer Ser- connected to the electricity supply in vices.
  • Page 7 1 Safety precautions ▪ Do not leave the appliance unattended ▪ When cleaning the appliance make when drying herbs, bread, mushrooms, sure no water gets inside it. Use a mod- etc. If the foodstuff dries out too much, erately damp cloth. Do not spray the it can pose a fire hazard.

  • Page 8: Using For The First Time

    Using for the first time Before operating the newly installed appliance for the first time, the following steps should be taken: ▸ Remove packaging and transport materials from out of the cooking space. ▸ Clean the cooking space and the accessories. ▸...

  • Page 9: Operating And Display Elements

    Cooking space temperature Operating mode Illuminated symbols Heating status Operation indicator V-ZUG-Home Cooking space Using protective inserts or aluminium foil can damage the appliance! Do not place any protective insert or aluminium foil on the floor of the cooking space.

  • Page 10: Accessories

    3 Appliance description Accessories Incorrect handling can cause damage! Do not use knives or cutting wheels on the accessories. Observe the correct use of the grill and oven furniture! Baking tray ▪ Baking tin for flans and biscuits ▪ Use together with the wire shelf as a drip tray. ▪...

  • Page 11: Operating Modes

    4 Operating modes Operating modes All the operating modes are described below. ▸ Place tins, moulds, etc. on the wire shelf. ▸ Ensure that the «sloped» side of the baking tray is to the back of the cooking space. Follow the advice in «Tips and tricks» in the separate «EasyCook brochure». Top/Bottom heat Temperature range 30–280 °C...

  • Page 12: Top/Bottom Heat Eco

    4 Operating modes Top/bottom heat eco Temperature range 30–250 °C Recommended value 200 °C Level 2 (or 1) This operating mode is particularly energy-efficient. The cooking space is heated by the top and bottom heating elements. Any moisture that escapes from the food is retained in the cooking space, so the food dries out less.

  • Page 13: Operating The Appliance

    5 Operating the appliance Operating the appliance dials beside the operating panel are for operating the oven and the outer and dials (if any) are for operating the hob. Cooking space illumination The cooking space illumination must be switched on manually. ▸...

  • Page 14: V-Zug-Home

    Connecting the appliance to the home network ▸ In the V-ZUG App, add the household appliance. – The name of the active WLAN/Wi-Fi appears in the V-ZUG App and then you are prompted to enter the WLAN/Wi-Fi password. ▸ Enter the WLAN/Wi-Fi password.

  • Page 15: User Settings

    – The connecting mode is active for 60 seconds. ▸ Connect the appliance to the home network within this time (see page 14). – The symbol illuminates. – The V-ZUG-Home operating mode is switched on. Switching off ▸ Turn the dial to the position.

  • Page 16: Hob

    8 Hob Depending on the model, the cooker comes with a glass ceramic hob or hotplates. In the case of a glass ceramic hob, please follow the relevant operating instructions. Never switch the hotplates on, especially at a high power level, without any cook- ware as overheating can damage them.

  • Page 17: Cookware

    8 Hob Cookware Suitable cookware Cookware should have a stable bottom. When heated, the base of the cookware must lie flat on the surface of the cooking zone. Cookware made of metal is more suitable than that made of glass or ceramic as with metal the heat is distributed evenly quicker.

  • Page 18: Cleaning And Care For Hotplates

    9 Care and maintenance Switching cooking zone off ▸ Set the dial for the required cooking zone to power level «0». – If the other cooking zones are switched off and the oven is not running, the power indicator light goes out. Cleaning and care for hotplates Risk of burns! Allow the appliance to cool down before cleaning.

  • Page 19: Replacing The Door Seal

    9 Care and maintenance Replacing the door seal Removing the door seal ▸ In each of the four corners, turn the seal out- wards by about 30° and carefully pull the clip out of the slot. ▸ When all four clips have been released, re- move the seal.
  • Page 20 9 Care and maintenance Removing the appliance door The appliance door is heavy. When removing and reinstalling the appliance door, hold it at the sides firmly with both hands. ▸ Open the appliance door as far as it will go. ▸...
  • Page 21 9 Care and maintenance Cleaning the door glass ▸ Lay the appliance door on a clean, flat surface (covered e.g. with a tea towel) with the handle facing down. – Make sure the handle does not come into contact with the surface. ▸...

  • Page 22: Cleaning The Accessories And Shelf Guides

    9 Care and maintenance Cleaning the accessories and shelf guides ▪ The wire shelf and shelf guides can be cleaned in the dishwasher. ▪ The baking tray can be cleaned in the dishwasher; however, this will affect its non- stick properties. Removing and putting back the shelf guides When inserting the shelf guides take care not to damage the enamel.

  • Page 23: Trouble-Shooting

    10 Trouble-shooting Trouble-shooting You may be able to trouble-shoot the following malfunctions yourself. If not, call Cus- tomer Services. 10.1 Error messages Message Possible cause Solution The appliance is not ▪ A household fuse or circuit ▸ Set all the dials to «0». working breaker has tripped.

  • Page 24: Accessories And Spare Parts

    11 Accessories and spare parts Accessories and spare parts Please give serial number of the appliance and exact designation of the accessory or spare part when ordering parts. 11.1 Accessories Baking tray Wire shelf EasyCook brochure 11.2 Special accessories For information see: www.vzug.com 11.3 Spare parts...

  • Page 25: Temperature Measurement

    Brand – V-ZUG Ltd Type of appliance – Oven | Cooker Model designation – Combair V200 Model number 21036, 21037, 21074, 22017, 22018, 22023, 22024 Mass of SMS 55-600 | 55-762 appliance - | 45 Mass of EURO 60-600 | 60-762 appliance...

  • Page 26: Tips And Tricks

    13 Tips and tricks Tips and tricks 13.1 Baking and roasting Result Solution ▪ The baking or roast ▸ Next time, set a lower temperature and lengthen the operat- looks good on the ing time. outside but is still ▸ Check that the settings selected correspond to those re- doughy or raw on the commended in the separate «EasyCook brochure».

  • Page 27: Disposal

    14 Disposal Disposal 14.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 14.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸...

  • Page 28: Index

    Index Replacing ............ 22 Accessories ..........10, 24 Appliance Identification plate..........24 Disposal............ 27 Initial set-up ............8 Appliance door Reinstalling............  20 Removing ............ 20 Levels ..............9 Appliance drawer Cleaning ............ 18 Malfunctions............23 Model designation ..........2 Baking and roasting ........26 Baking tray ..........
  • Page 29 Top/bottom heat humid........11 Type............... 2 Uneven browning ..........26 User settings............. 15 Using for the first time........8 Validity..............2 V-ZUG App ............14 V-ZUG-Home App access...........  15 Resetting ............ 15 Switching off .......... 15 Switching on .......... 15 Wire shelf............

  • Page 30: Notes

    Notes...

  • Page 31: Service & Support

    Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
  • Page 32 – If there are no cooking zones switched on on the cooker, the symbol goes out. 1038025-05 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
