Max. operating current and recommended fuse
rating when connected 3x400 V
Max. operating current compressor
Max operating current heat pump including 3 kW
immersion heater, compressor working and enabled
contactor K1 (Recommended fuse rating)
Max operating current heat pump including 6 kW
immersion heater, compressor working and enabled
contactor K1+K2 (Recommended fuse rating)
Max operating current heat pump including 9 kW
immersion heater, compressor working and enabled
contactor K1+K2 +K3 (Recommended fuse rating)
Max operating current 9 kW immersion heater, com-
pressor not working and enabled contactor K1+K2
+K3 (Recommended fuse rating)
Max. operating current and recommended fuse
rating when connected 1x230 V
Max. operating current compressor
Max operating current heat pump including 1,5 kW
immersion heater, compressor working and enabled
contactor K1 (Recommended fuse rating)
Max operating current heat pump including 3 kW
immersion heater, compressor working and enabled
contactor K1+K2 (Recommended fuse rating)
Max operating current heat pump including 4,5 kW
immersion heater, compressor working and enabled
contactor K1+K2 +K3 (Recommended fuse rating)
Max operating current 4,5 kW immersion heater,
compressor not working and enabled contactor
K1+K2 +K3 (Recommended fuse rating)

Performance

Outdoor module / HT 6Split / HT 12Split
Heating
Output data according to EN14511
ΔT5K
Specified/supplied power/COP (kW/
kW/-)
Cooling
Output data according to EN14511 ΔT5K
Specified/supplied power/EER
HT 6Split
HT 12Split
Unit
A
A
A
A
A
Unit
A
A
A
A
A
L6Split /
HT 6Split
Outd. temp. /
Nominal
Supply temp.
7/35°C (floor)
2,67/0,5/5,32
2/35°C (floor)
2,32/0,55/4,2
7/45°C
2,28/0,63/3,62
2/45°C
1,93/0,67/2,88
Outd. temp. /
Max.
Supply temp.
27/7°C
5,87/1,65/3,56
27/18°C
7,98/1,77/4,52
35/7°C
4,86/1,86/2,61
35/18°C
7,03/2,03/3,45
HT 6Split HT 12Split
+ L6Split + L8Split
16 16
16 (20) 16 (20)
16 (20) 16 (20)
20 (20) 20 (20)
20 (20) 20 (20)
HT 6Split HT 12Split
+ L6Split + L8Split
16 16
22,5 (25) 22,5 (25)
29 (32) 29 (32)
35,5 (32) 35,5 (32)
19,5 (20) 19,5 (20)
L8Split /
HT 12Split
Nominal
3,86/0,83/4,65
5,11/1,36/3,76
3,70/1,00/3,70
5,03/1,70/2,96
Max.
7,52/2,37/3,17
11,20/3,20/3,50
7,10/2,65/2,68
9,19/2,98/3,08
Chapter 13 |
HT 12Split
+ L12Split
20
20 (20)
20 (20)
20 (20)
20 (20)
HT 12Split
+ L12Split
20
26,5 (25)
33 (32)
39,5 (40)
19,5 (20)
L12Split /
HT 12Split
Nominal
5,21/1,09/4,78
6,91/1,79/3,86
5,00/1,31/3,82
6,80/2,24/3,04
Max.
9,87/3,16/3,13
11,70/3,32/3,52
9,45/3,41/2,77
11,20/3,58/3,12
Technical data 69
