Pipe dimensions and materials
HT 12Split
HT 12Split Gas pipe
Pipe replacement Ø15,88 mm (5/8")
Connection Connection – (5/8") Connection – (3/8")
Quality of copper SS-EN 12735-1 or
Material
Minimum ma-
1,0 mm
terial thickness
HT 6Split
HT 6Split Gas pipe
Pipe replace-
Ø12,7 mm (1/2")
ment
Connection Connection – (1/2") Connection – (1/4")
Quality of copper SS-EN 12735-1 or
Material
Minimum ma-
1,0 mm
terial thickness
Pipe connection
• Execute the pipe installation with the mainte-
nance valves (QM35, QM36) closed.
L6Split / L8Split: Remove the side panel on LSplit
•
during the installation to make access easier.
L12Split:Remove the "to be removed" part from
•
the external panel at the LSplit mode where pipes
are to be led. The drawing below presents exem-
plary pipe outlets.
Front
• Make sure that no water or dirt can permeate to the
pipes. Contamination of the pipes may damage
the heat pump.
HT 6Split
HT 12Split
Liquid pipe
Ø9,52 mm (3/8")
C1220T, JIS H3300
0,8 mm
Liquid pipe
Ø6,35 mm (1/4")
C1220T, JIS H3300
0,8 mm
Elements to be removed
• Bend pipes with maximum bending radius (at
least R100~R150). Do not bend pipes many
times. Use a bending machine.
• Connection of refrigerant pipes to the outdoor unit
and indoor unit should be perform with flare con-
nections after prior dismantling of production ends.
• Connect the socket connection and tighten with
appropriate torque. Apply the appropriate tight-
ening angle if the torque wrench is not available.
External
diameter, Torque
copper (Nm)
pipe (mm)
Ø6,35 14~18
Ø 9,52 34~42
Ø12,7 49~61
Ø 15,88 68~82
A
IMPORTANT
When soldering, apply the shielding gas.
Socket connections
B
Extension:
Serviceventil, vätska
External diameter,
copper pipe
Ø 6,35
Ø 9,52
Ø 12,7
Ø 15,88
Shift:
External diam-
B, using
eter, copper
R410A (mm)
pipe (mm)
Ø 9,52
Ø 15,88
0,0~0,5
Ø 6,35
Ø 12,7
Recom-
Tightening
mended
angle
tool length
(°)
(mm)
45~60 100
30~45 200
30~45 250
15~20 300
Wyjście pomiarowe
Mätuttag
Zawór serwisowy,
A
ciecz
Zawór serwisowy,
Pompa
Serviceventil, gas
gaz
próżniowa
A
A (mm)
9,1
13,2
16,6
19,7
B
B
B, using a
conventional
tool (mm)
0,7~1,3
1,0~1,5
Chapter 4 |
Pipe connections
Manometr
Manometer
Vacuum
pump
Wyjście
Zawór serwisowy,
Wyjście po
Serviceventil, vätska
ciecz
Zawór serwisowy,
Serviceventil, gas
Zawór serwisowy,
gaz
Serviceventil, vätska
ciecz
Zawór serwisowy,
Serviceventil, gas
gaz
