Menu 5.2.2 - Installed slave devices
If a slave device is connected to the master installa-
tion, it is specified here.
There are two ways of activating connected slave de-
vices. You can either select the given option in the list
or use the automatic function "search installed slave
devices".
Search installed slave devices
Select "search installed slave devices" and press the
OK button to automatically find connected slaves for
the master heat pump.
Menu 5.2.4 - Accessories
Here is where it states if an accessory is installed
(see "Accessories" section).
There are two ways of activating connected accesso-
ries. You can either select the given option in the list
or use the automatic function "search installed acces-
sories".
Search installed accessories
Select "search installed accessories" and press the
OK button to automatically find connected accesso-
ries for the controller.
ACTIVE COOLING 4 PIPE
In order to activate 4-pipe cooling, select the function
"active cooling 4 pipe" .
HT 6Split
HT 12Split
Menu 5.3 - Accessory settings
The operating settings for installed and activated ac-
cessories are entered in the submenus for this.
NOTE
Menu 5.3 is deactivated in the factory settings. For this
menu function to be active, it is necessary to install an
accessory and activate it in the Accessories menu 5.2.4.
For a detailed description of how to program accessories,
refer to the instructions of the individual accessories.
Menu 5.3.2 - Add. heat. ctrl shunt valve
NOTE
Menu 5.3.2 is deactivated in the factory settings. For this
menu function to be active, it is necessary to install ac-
cessory EP Split and activate it in the Accessories menu
5.2.4.
For a detailed description of how to program accessories,
refer to the instructions of the individual accessories.
Menu 5.3.3 - Additional climate system
NOTE
Menu 5.3.3 is deactivated in the factory settings. For this
menu function to be active, it is necessary to install an
additional accessory and activate it in the Accessories
menu 5.2.4.
For a detailed description of how to program accessories,
refer to the instructions of the individual accessories.
Menu 5.3.6 - step controlled add. heat
NOTE
Menu 5.3.6 is deactivated in the factory settings. For this
menu function to be active, it is necessary to install ac-
cessory EP Split and activate it in the Accessories menu
5.2.4.
For a detailed description of how to program accessories,
refer to the instructions of the individual accessories.
