5.3.4

Expert menu (TIG)

The Expert menu has adjustable parameters stored that don't require regular setting. The number of pa-
rameters shown may be limited, e.g. if a function is deactivated.
Display
099-007033-EW501
4.1.2022
ENTER
Setting/selection
Expert menu
Start time (duration of start current)
Slope time (main current to secondary current)
Slope time (secondary current to main current)
End current time (duration of end current)
Ignition type (TIG)
-------HF start active (ex works)
-------Lift arc ignition active
Figure 5-20
Design and function
TIG welding
EXIT
41
