Technical data

Microplasma 105-2 PG RC

8.3 Microplasma 105-2 PG RC
Welding current (I
Welding voltage according to standard (U
Plasma current (pilot arc)
Duty cycle DC at 40° C
100 %
60 %
Open circuit voltage (U
Ignition voltage (U
Mains voltage (Tolerance)
Frequency
mains fuse
[2]
Mains connection cable
max. Connected load (S
Generator rating (Rec.)
Cos φ
Protection class / Overvoltage category
Contamination level
Insulation class / protection classification
Residual current circuit breaker
Noise level
[3]
Ambient temperature
Machine cooling / Torch cooling
Workpiece lead (min.)
EMC class
Safety marking
Standards used
Dimensions (l x b x h)
Weight
Load cycle: 10 min. (60 % DC ≙ 6 min. welding, 4 min. pause)
[1]
Safety fuses are recommended DIAZED xxA gG. When using automatic cutouts, the "C" trigger char-
[2]
acteristic must be used.
Noise level during idle mode and operation under standard load according to IEC 60974‑1 at the maxi-
[3]
mum operating point.
Ambient temperature dependent on coolant! Observe coolant temperature range!
[4]
64
)
2
2
[1]
)
0
)
P
)
1
[4]
Plasma
0,3 A to 100 A
) 25,0 V to 29,0 V
70 A
100 A
1 x 230 V (-40 % to +15 %)
1 x 20 A
5,8 kVA
Type B (recommended)
Fan (AF) / Cooling unit, ext.
See declaration of conformity (appliance documents)
625 x 377 x 531 mm
24.6 x 14.8 x 20.9 inch
TIG
2 A to 100 A
10,1 V to 14,0 V
2-6 A
100 A
-
95 V
12 kV
50/60 Hz
1 x 16 A
H07RN-F3G2,5
3 kVA
7,8 kVA
0,99
Ⅰ / Ⅲ
3
H / IP 23
<70 dB(A)
-25 °C to +40 °C
25 mm
2
A
/ /
36,6 kg
79.8 lb.
