Table 5: Media Specifications (LPe36000-Series HBAs and LPe35000-Series HBAs) (Continued)
Fiber-Optic Cable
OM2 – Multimode 50/125 micrometer fiber
(500 MHz × km bandwidth cable)
OM1 – Multimode 62.5/125 micrometer fiber
(200 MHz × km bandwidth cable)
OS2 – Single-mode 9/125 micrometer fiber
(0.4 dB/km attenuation, type B1.3)
OS1 – Single-mode 9/125 micrometer fiber
(1.0 dB/km attenuation, type B1.1)
Table 6: Media Specifications (LPe32000-Series HBAs and LPe31000-Series HBAs)
Fiber-Optic Cable
OM4 – Multimode 50/125 micrometer fiber
(4700 MHz × km bandwidth cable)
OM3 – Multimode 50/125 micrometer fiber
(2000 MHz × km bandwidth cable)
OM2 – Multimode 50/125 micrometer fiber
(500 MHz × km bandwidth cable)
OM1 – Multimode 62.5/125 micrometer fiber
(200 MHz × km bandwidth cable)
OS2 – Single-mode 9/125 micrometer fiber
(0.4 dB/km attenuation, type B1.3)
OS1 – Single-mode 9/125 micrometer fiber
(1.0 dB/km attenuation, type B1.1)
Broadcom
Maximum Length
8GFC: 0.5m to 50m
16GFC: 0.5m to 35m
32GFC: 0.5m to 20m
64GFC: N/A
8GFC: 0.5m to 21m
16GFC: 0.5m to 15m
32GFC: N/A
64GFC: N/A
8GFC: 0.5m to 10 km
16GFC: 0.5m to 10 km
32GFC: 0.5m to 10 km
64GFC: 0.5m to 10 km
8GFC: 0.5m to 10 km
16GFC: 0.5m to 10 km
32GFC: 0.5m to 10 km
64GFC: N/A
Maximum Length
4GFC: 0.5m to 400m
8GFC: 0.5m to 190m
16GFC: 0.5m to 125m
32GFC: 0.5m to 100m
4GFC: 0.5m to 380m
8GFC: 0.5m to 150m
16GFC: 0.5m to 100m
32GFC: 0.5m to 70m
4GFC: 0.5m to 150m
8GFC: 0.5m to 50m
16GFC: 0.5m to 35m
32GFC: 0.5m to 20m
4GFC: 0.5m to 70m
8GFC: 0.5m to 21m
16GFC: 0.5m to 15m
32GFC: N/A
4GFC: 0.5m to 10km
8GFC: 0.5m to 10km
16GFC: 0.5m to 10 km
32GFC: 0.5m to 10 km
4GFC: 0.5m to 10 km
8GFC: 0.5m to 10 km
16GFC: 0.5m to 10 km
32GFC: 0.5m to 10 km
Minimum Length Connector
0.5 meters LC
0.5 meters LC
0.5 meters LC
0.5 meters LC
Minimum Length
0.5 meters
0.5 meters
0.5 meters
0.5 meters
0.5 meters
0.5 meters
Connector
LC
LC
LC
LC
LC
LC
