7. Installer mode

To enter installer parameters please follow steps below. Please refer to parameters table description before any changes. Use
up or down between all parameters. Every change/selection confirm by
1
3 sec
simultanously for about 3 seconds to
DETAILED TABLE WITH ALL INSTALLER PARAMETERS:
dxx
d01 Temperature display increments
d02 Temperature offset
d03 Frost Protection setpoint temperature
d04 Programmer selection

7.1 DIP switches parameters

DIP switched are used to set chosen control algorithm. They are under back cover of the thermostat (please refer to the picture below):
Type of control
TPI
When TPI is selected on DIP switch № 2, the
DIP switch № 1 is functional. You can choose
How it works
the Cycles Per Hour between a lower
comfort level (6CPH) and a higher comfort
level (9CPH).
20
3 sec
TEST / PAIRING
SELECT SET
3 sec
Press and hold + +
enter the installer mode.
Function
button.
2
parameter, confirm selection by SET
button. To change parameter value
TEST / PAIRING
SELECT SET
use
selection by SET button. To exit the
installer mode, wait 10 seconds -
thermostat will re-turn automatically
0.1°C or 0.5°C
+/- 3.0°C
5.0°C - 17.0°C
5/2 or 24 hr (7d)
Hysteresis
When Span is selected on DIP switch № 2, the
DIP switch № 1 is not functional. The SPAN
value is set to ± 0.25°C - it is recommended to
use with heating devices.
TEST / PAIRING
SELECT SET
Use SELECT button to choose
or buttons and confirm
to the main screen.
Parameter
0.5°C
0.0°C
5.0°C
5/2 d
or buttons to move
Default
value
ON
Span
9CPH ±0.25°C
6CPH TPI
1 2
