4. Before you start (first power up)

4.1 LCD icon description

4.2 Button description

PLEASE NOTE! The LCD screen can be activated by using any button.
15
1
2
3
1. Day of the week
2. Program number
3. Program indicator
4. Settings
5. Temperature measured / set
6. Boost function
7. Low battery status
8. Wireless connection with the receiver
1
2
1. Boost function
2. Manual Mode
3. Frost protection / Holiday Mode
14 13 12
4 5 6
9. Heating Mode On
10. Manual Mode On
11. Holiday Mode On
12. Frost Protection Mode On
13. Temperature unit
14. AM / PM
15. Clock
4. Increase button
5. Decrease button
11
10
9
8
7
3
4
5
11
